42
PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
D13 3966010420 MOTOR SYNCRONOUS 220~240V/50,60HZ,18,1806 1
3966010430 220~240V/50,60HZ,23,1806
3966130320 100V/50,60HZ,18,1806
3966130330 100V/50,60HZ,23,1806
3966320800 110~120V/60HZ,18,1806
3966320810 110~120V/60HZ,23,1806
3618957620 220~240V/50,60HZ,18,1806 INVERTER
D14 3617307100 GEAR MECHANISM GM-2000-KJ6XO 1
3617308300 GM-2000-KS6X2
D15 7640802011 BOLT HEX 6B-1 8X20 SW MFZN 4
D16 3618301300 PROTECTOR GEAR SBHG 1.6T 1
D17 3616500500 BELT V M20.5 1
3616590230 M21, AGING INVERTER
D18 3614800710 SENSOR HALL AS DWF-100MV, 5.4V 1 INVERTER
D19 3611502700 CUSHION DOWN POM(8MM) 2
D20 3964321250 MOTOR CONDENSER 220V/60HZ,W1D50UA001 1
3964131120 100V/50,60HZ,W1D50BA001
3964221220 110~127V/60HZ,W1D50CA001
3964821320 120~127V/60HZ,W1D50JA001
3964510420 220~240V/50HZ,W1D50VA001
3964320920 220V/60HZ,WM244GA010
3618956310 W1N44UA302 3-BRACKET INVERTER
D21 3611502000 CUSHION UPPER POM 107X31X6.7 2
D22 7650802811 BOLT HEX 6B-1 8X28 HS MFZN 2
D23 3618401400 PULLEY MOTOR AS ADC-12, DS=10, DP=48.5 1
3618401420 ADC-12, DS=10, DP=53.0
3618403510 ADC-12 DS=12 DP=52.5
3618431300 ADC-12. DP=60.5, 50HZ INVERTER
D24 3610402910 BODY BUBBLE AS 98 SERIES (MOTOR TYPE) 1 OPTION
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
