Daewoo DWF-700M - Parts List

19
PARTS DIAGRAM
■
Parts List
NO. PARTCORD PART NAME SPEC Q’ TY UNIT NOTE
A01
3610906800
CAP VALVE
PP(INLET) 2 EA
3610906800 PP(INLET) 1 EA SINGLE VALVE
A02
3612300110
GASKET VALVE
PVC-S(INLET) 2 EA
3612300110 PVC-S(INLET) 1 EA SINGLE VALVE
A03 7122402011 SCREW TAPPING T2S TRS 4X20 MFZN 2 EA
A04 3614231100 PANEL B PP 1 EA
A05 3614201300
SENSOR PRESSURE AS 0˚C CDN-D6N CUS-D6N 1 EA
A06
3619006380
SWITCH SAFETY
DC 15V 040P
1 EA
3619003170 DC 15V 5F-040A3 14mm
A07 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 2 EA
A08 4507D08150 CLAMP MFZN HOSE ID=Ø7 1 EA
A09 3611305500 POWER CORD AS A-VCTFK 2X0.75 2.3M GY 1 EA TAIWAN
3611304600 N LFC-3R 3X0.75 2.3M GY AUSTRLIA
3611304700 F H05W 3X0.75 2.3M WH CHILE
3611304800 RW-300/500 3X0.75 2.3M CHINA
3611304900 VCTF 3X0.75 2.3M INDIA
3611305300 H05W-F 3X0.75 2.3M WH MALAYSIA
3611305400 H05W-F 3X0.75 2.3M BK SINGAPOLE
3611305800 H05W-F 3X0.75 2.3M GY SOUTH AFRICA
3611305600 F H05W 3X0.75 2.3M BK USSR
3611306020 H05W-F 3X0.75 2.3M GY ARGENTINA
3611305100 3X0.75 2.3M KOREA
A10 3613225900 HOSE AS ID=4.0, L=600, JOINT(2FA) 1 EA
A11 3615403530 VALVE INLET(C) AC110-130V/60Hz 90 1 EA 110-130V/60Hz
3615403730 AC220-240V/50Hz 90 220-240V/50Hz
3615402030 AC220V/60Hz 90 220V/60Hz
A12 3615403610 VALVE INLET(H) AC110-130V/60Hz 270 1 EA 110-130V/60Hz
3615403810 AC220-240V/50Hz 270 220-240V/50Hz
3615402110 AC220V/60Hz 270 220V/60Hz
A13 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 4 EA
A14 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 2 EA
A15 3614519300 PLATE T PP 1 EA
A16 3618102400 NOZZLE DETERGENT PP 1 EA
A17 3611119600 CASE DETERGENT PP 1 EA
A18 3612902400 HINGE DOOR POLYACETAL 1 EA
A19 3615111200 SPRING DOOR R SUS 304 1 EA
A20 3611796300 DOOR B PP 1 EA
A21 3611796400 DOOR F PP 1 EA
3611796500
A22 3615502100 WINDOW DISPLAY ABS 1 EA
3612604400 HANDLE DOOR PP 1 EA
A23 3610906710 CAP PP 2 EA
A24 7112503011 SCREW TAPPING T1S TRS 5X30 MFZN 2 EA
