20
PARTS DIAGRAM
NO. PARTCORD PART NAME SPEC Q’ TY UNIT NOTE
A25 3614231200 PANEL F ABS 1 EA
A26 3611616400 DECORATOR PANEL F PET 1 EA
A27 PRPSSWX700 PCB AS DWF-850M
220-240V(NON PUMP)
PRPSSWX800 DWF-170MTC 110-130V(NON PUMP)
PRPSSWX900 DWF-170MNP 220-240V(PUMP)
PRPSSWXE00 DWF-170MSP 110-130V(PUMP)
PRPSSWXB00 DWF-173MNE
220-240V(NON PUMP)
PRPSSWXC00 DWF-173MTC 110-130V(NON PUMP)
PRPSSWXD00 DWF-173MNP 220-240V(PUMP)
PRPSSWXF00 DWF-173MSP 110-130V(PUMP)
A28 7121401211 SCREW TAPPING T2S PAN 4X12 MFZN 4 EA
A29 3612760400 HARNESS AS DWF-850M 1 EA NON PUMP
3612760410 DWF-170MTC COLD ONLY
3612760420 DWF-170MNP PUMP
*DWF-700M: DOOR A TYPE (A21) + PANEL A TYPE (A25)
B01 3611201000 CLAMP HSW3, D2.6, MFZN D36 1 EA NON PUMP
3611202200 HSW3 PE-LD PUMP
B02 3613220200 HOSE DRAIN O AS ASSY(PE-LD+EVA L=1250) 1 EA NON PUMP
3613217800 HOSE DRAIN O PE-LD PUMP
B03 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 4 EA
B04 3614519400 PLATE UPPER PP 1 EA
B05 3615302930 SUPPORTER TUB BL POM 1 EA
B06 7112401211 SCREWTAPPING T1 TRS 4X12 MFZN 1 EA
B07 3615302920 SUPPORTER TUB BR POM 1 EA
B08 3515302900 SUPPORTER TUB FR POM 1 EA
B09 3615302910 SUPPORTER TUB FR POM 1 EA
B10 3611414010 COVER B 372X508X0.4T SGCC 1 EA
B11 3618921500 ASSY CONDENSER 54.0µF+60µH L=470 #250 1 EA 110V/60Hz
3618921900 41.6µF+60µH L=470 #250 127V/60Hz
3618921000 13.5µF+60µH L=470 #250 220V/50Hz, 60Hz
3618913740 11.4µF+60µH L=470 #250 240V/50Hz
B12 3612603300 HANDLE CABINET PP 2 EA
B13 3610809500 CABINET AS SGCC 1 EA
3610388700 BASE U AS 850M 1 EA ASSY(B14~B16)
B14 3610388300 BASE U PP 1 EA
B15 3617702100 LEG ADJUST AS DWF-1089W2 1 EA
B16 3617702300 LEG FIX
THERMAL PLASTIC ELASTOM 3 EA
B17 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 12 EA
B18 3611403710 COVER UNDER PP 1 EA
B19 3611405320 COVER PUMP PP(B360F) 1 EA
3611405301 UL/CSA(466FWU, HFH-400)
B20 7112501611 SCREW TAPPING T1 TRS 5X16 MFZN 2 EA
