PARTS DIAGRAM
NO. PARTCORD PART NAME SPEC Q’ TY UNIT NOTE
B21 3963220330 MOTOR SHADED POLE AC 110V/60Hz 1 EA 110v/60Hz
3963821530 AC 120V/60Hz 127V/60Hz
3963322730 AC 220V/60Hz 220V/60Hz
3963513430 AC 220-240V/50Hz 220-240v/50Hz
B22 3611901530 FILTER AS DWF-5591DPNF E-TYPE 1 EA
B23 3618703770 THEMINAL PUMP AC 125V/3.15A #250CONN 1 EA 110-130V/60Hz
3618703760 AC 250V/1A #250CONN 220-240V/50Hz
C01 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN 4 EA
C023611408500COVER TUB OPP1EA
DWF-700M
C03 3610910600 CAP PULSATOR PP 1 EA
C04 4505E3203A SC. PULSATOR FIX AS 6X25 O-RING+SILOCK 1 EA
C05 36169705800 PULSATOR AS PP DWF-850M 1 EA
C06 3616006200 SPECIAL NUT ZDC2 1 EA
C07 3616006500 SPRCIAL WASHER SUS301 T-0.8 1 EA
C08 3619704500 SUSPENSION AS (B) 850M 2 EA
C09 3619804400 SUSPENSION AS (A) 850M 2 EA
3618816800 TUB I AS 850M 1 EA ASSY(C10~C14)
3618803010 DWF-8080R2 ASSY(C10~C14)
3618803040 DWF7080 ASSY(C10~C14)
3616105500850M
DWF-700M
C103616101600BALANCER ASDWF-8080R21EA DWF-700M
C113618801700TUB ISUS1EA DWF-700M
C123618802000TUB UPP1EA DWF-700M
C13 GUIDE FILTER AS
3612508400
3612802200DWF-8080R21EA
DWF-700M
C14 3617200600 FLANGE TUB ALDC12 VE1 1 EA
C15 FILTER AS
3610085520PP 94’S (74X130X130)1EA
DWF-700M
C163618802630TUB OPP1EA DWF-700M
C17 4507D08150 CLAMP MFZN HOSE ID-Ø7 I EA
C18 4500D08210 HOSE ID=4.0 1 EA
C19 3615404020 VALVE DRAIN AS 5591D VE 1 EA
ONLY NON PUMP
C20 3613218500 HOSE DRAIN I AS LDPE+EVA L=219.5 1 EA NON PUMP
3613212100 HOSE DRAIN I LDPE+EVA L=184 PUMP
C21 3613208900 HOSE OVERFLOW PE-LD L=280mm 1 EA
ONLY NON PUMP
