PARTS DIAGRAM
NO PARTS NAME PARTS CODE EA DESCRIPTION REMARK
3618921000 13.5µF+60µH, L=470 220V/50,60Hz
3618920800 11.4µF+60µH, L=470 240V/50Hz
B11 CABINET AS
1
3610808320 PAINTING DWF-7094
B12 HANDLE CABINET 3612603300 2 PP
B13 BASE U 3610303100 1 PP
B14 LEG FIX 3617703000 2 SBS
B16 COVER UNDER 3611402711 1 PP
B17 HARNESS OUTER 3610068700 1 50/0.18 GREEN
B20 COVER PUMP
3611405320
1
PP(B360F) PUMP MODEL
3611405301
UL/CSA(466FWU,HFH-400)
PUMP MODEL
B21 SCREW TAPPING 7122501611 2 T2 TRS 5x16 MFZN PUMP MODEL
3618957310 AC110-127V/60Hz DWF-**94PT/PS
B22
MOTOR SHADED POLE
3618957280
1
AC 220V/60Hz DWF-**94PL
3618957250 AC 220V/50Hz DWF-**94PN
3618957220 AC 240V/50Hz DWF-**94PM
B23 FILTER AS 3611901530 1 DWF-5590DPNF, E-TYPE PUMP MODEL
B24 FRAME TOP 3612200100 1 PP
C01 BALANCER AS 1
3616101700 DWF-7094
C02 FILTER 4505E82014 1 POLYESTER FILTER AS
C03 FRAME FILTER 4505E82021 1 PP :4505E82002
C04 – – – –
C05 SPECIAL SCREW 3616003700 24 SUS 5.5x16
C06 GUIDE FILTER AS 1
3612502400 DWF-7094
C07TUB 1
3618801800 SUS430D DWF-7094
C08TUB U 1
3618802101 PP, -M/B DWF-7094
C09 SPECIAL NUT 4507D83080 1 SUS 304
C11 FLANGE TUB
1
3617200610 ADC 10, 6.6-7.0kg DWF-7094
C12 SPECIAL SCREW 3616007000 3 SCM24H, 6.5x24
C13 CAP PULSATOR 3610908300 1 PP
C14 SPECIAL SCREW 3616003720 1 SUS 6x26.5
C15 PULSATOR AS 3619703700 1 PULSATOR+INSERT
D01 1
COVER TUB O 3611408400 PP DWF-7094
