PARTS DIAGRAM
NO PARTS NAME PARTS CODE EA DESCRIPTION REMARK
D02TUB O 1
3618802510 PP JI-370 DWF-7094
D03
SUSPENSION AS(A)
2
3619800410 DWF-7094 WHITE
D04
SUSPENSION AS(B)
2
3619800510 DWF-7094 YELLOW
D06 HOSE 4500D08210 1 ID=4.0, L=620mm
D07 HOSE DRAIN I AS
3613218500
1
PE-LD, EVA(L=219.5) NON-PUMP
3613212100 LDPE+EVA, L=184 PUMP MODEL
D08
HOSE OVERFLOW
3613208901 1 PE-LD L=280mm NON-PUMP
D09 VALVE DRAIN AS 3615408400 1 100M NON-PUMP
D10 BASE 3610387400 1 SECEN 2.0t
D11
HARNESS EARTH INNER
3612757010 1 L=560mm
D12
MOTOR SYNCHRONOUS
450ED45120
1
AC 110-130V/50,60Hz ST=23
3966010220 AC 220-240V/50,60Hz ST=23
D13 SPECIAL SCREW 3616007000 12 SCM24H, 6.5x24
D15 BELT V
3616590220
1
M20.5, AGING 60Hz
3616590230 M21, AGING 50Hz
D16
GEAR MECHANISM
3617307610 1 GM-1300-KS6P0
D17 BOLT HEX 7341801511 4 6B-1, 8*15, MFZN
D18
PROTECTOR GEAR
3618301300 1 SBHG1, 1.6T
D19 CUSHION DOWN 3611502700 2 P.O.M, H=8mm
3966221101 AC 110-127V/60Hz W1D46CA002-S
D20
MOTOR CONDENSER
3964321111 1 AC 220V/60Hz W1S46UA012
3964311311 AC 220-240V/50Hz W1D46VA012-S
D22
PULLEY MOTOR AS
3618432000
1
ADC-12, DS=10, DP=48.5
60Hz
3618431900
ADC-12, DS=10, DP=53.0
50Hz
D23 BOLT HEX 7650804211 2 6B-1 8x42 S.P/W MFZN
44
