PARTS DIAGRAM
NO PARTS NAME PARTS CODE EA DESCRIPTION REMARK
A01 GASKET VALVE 3612300110 2 PVC-S 1
EA;SINGLE VALVE
A02 PANEL B 3614217610 1 ABS
VALVE INLET AS
3615405560 220V/60Hz
(ONLY COLD)
3615405571 1 220-240V/50Hz
3615405550 110-130V/60Hz
A03 3615405500 220V/60Hz
VALVE INLET AS
3615405531
1
220-240V/50Hz
3615407500 220-240V/50Hz
3615405520 110-130V/60Hz
A05 HINGE DOOR 3612902400 2 POLYACETAL
A06 BUBBLE PUMP AS
3618918600
1
AC 110-130V/50,60Hz HOSE;830mm
3618919200 AC 220-240V/50,60Hz HOSE;830mm
A07 SENSOR PRESSURE 3614801110 1 D8T, TERMINAL
5EP1048010 T5-V1
AC 110-130V
A08 TRANS POWER
5EP1048020
1
T5-V1F
5EP1048030 T5-V2
AC 220-240V
5EP1048040 T5-V2F
A09 SWITCH SAFETY AS
3619008921
1
SF-030T, TUBE/T=0.5, #187
3619008931
SF-030T, TUBE/T=0.5, #187
AUSTRALIA
A10 PLATE T 3614514510 1 ABS
A11 CAP SOFTENER 3610907800 1 PP
A12 NOZZLE DETERGENT 3618101700 1 PP
A13 CASE DETERGENT 3611114700 1 PP
A14 SPRING DOOR 3615107410 1 SUS304 D=1.8
A15 DOOR B 3611717510 1 ABS
A16 DOOR F 3611717430 1 ABS
A17 HANDLE DOOR 3612603210 1 ABS
A18 CUSHION DOOR 3611504100 2 CR
A19 SCREW TAPPING 7112503011 2 T1 TRS 5x30 MFZN
A20 CAP 3610907900 2 NBR
A21 PANEL F 3614217510 1 ABS
3618914811 AC 250V/5A, FERRITE
A22 UNIT FUSE FILTER 3618918411
1
AC 250V/8A, FERRITE
3618952011 AC 250V/8A, T-TUBE TAIWAN
2. DWF-1094
