NO PARTS NAME PARTS CODE EA DESCRIPTION REMARK
3612726711 250V/315mA
SINGLE VALVE
A24 HARNESS AS
3612726731
1
250V/600mA
3612726721 250V/315mA
PUMP
3612726741 250V/600mA
3611302900 3x0.75, 300x2, L=1800 CP-2PIN
A25
CORD POWER AS
3611302800
1
A VCTFK 2x0.75 2.3M F-2PIN
3611302600 F H05W 3x0.75 2.3M ITALIAN 3PIN
3611303300 GTSA-3 3x0.75 GY ARGENTINE
A26 CLAMP 4500D08180 2 SWC BUBB ID=12.5
A27
HOSE SHOWER AS
3613223200 1 HOSE+ABSORBER
B02
HOSE DRAIN O 3613213560 1 EVA, L=950mm NON-PUMP
HOSE DRAIN O AS
3613218800 1 PE-LD/EVA, L=1600 PUMP
B03 PLATE UPPER 3614514600 1 PP
B04 COVER B 3611413600 1 SPG 0.5T
B05
SCREW TAPPING
7112501411 1 T1TRS 5x14 MFZN
B06
SUPPORT TUB BL
3615302210 1 SPG T1.4
B07
SUPPORT TUB BR
3615302310 1 SPG T1.4
B08
SUPPORT TUB FL
3615302410 1 SPG T1.4
B09 SUPPORT TUB FR 3615302510 1 SPG T1.4
3618921500 54.0µF+60µH, L=470 110V/60Hz
B10
ASSY CONDENSER
3618921900
1
41.6µF+60µH, L=470 127V/60Hz
3618921000 13.5µF+60µH, L=470 220V/50,60Hz
3618920800 11.4µF+60µH, L=470 240V/50Hz
B11 CABINET AS 3610808011 1 PAINTING
B12
HANDLE CABINET
3612603300 2 PP
B13 BASE U 3610310200 1 PP
B14 LEG FIX 3617702300 2
THEMAL PLASTIC ELASTOMER
B16 COVER UNDER 3611402711 1 PP
B17
HARNESS OUTER
3610068700 1 50/0.18 GREEN
B20 COVER PUMP
3611405320
1
PP(B360F)PUMP MODEL
3611405301
UL/CSA(466FWU,HFH-400)
PUMP MODEL
B21
SCREW TAPPING
7122501611 2 T2 TRS 5x16 MFZN PUMP MODEL
46
PARTS DIAGRAM
