47
PARTS DIAGRAM
NO PARTS NAME PARTS CODE EA DESCRIPTION REMARK
C02 FILTER 3611903300 2 NYLON, 100x150
FILTER AS
C03 FRAME FILTER 3611903000 2 PP
;3611903100
C04 HOLDER 3613008900 2 PP
C05
SPECIAL SCREW
3616003700 24 SUS 5.5x16
C07 TUB 3618806900 1 SUS430D
C08 TUB U 3618807001 1 PP, -M/B
C09 SPECIAL NUT 4507D83080 1 SUS 304
C11 FLANGE TUB 3617201200 1 10Kg, 3-FOOT
C12
SPECIAL SCREW
3616007000 3 SCM24H, 6.5x24
C13 CAP PULSATOR 3610908300 1 PP
C14
SPECIAL SCREW
3616003720 1 SUS 6x26.5
C15 PULSATOR AS 3619703500 1 PULSATOR+INSERT
D01
RING SHOWER AS
3614601700 1 RING T + RING U
D02 TUB O 3618807100 1 PP JI-370
D06 HOSE 4500D08210 1 ID=4.0, L=360mm
D07
HOSE DRAIN I AS
3613218500
1
PE-LD, EVA(L=219.5) NON-PUMP
3613212100 LDPE+EVA, L=184 PUMP MODEL
D08
HOSE OVERFLOW
3613208901 1 PE-LD L=280mm NON-PUMP
D09
VALVE DRAIN AS
3615408400 1 100M NON-PUMP
D10 BASE 3610387400 1 SECEN 2.0t
D11
HARNESS EARTH INNER
3612757010 1 L=560mm
D12
MOTOR SYNCHRONOUS
450ED45120
1
AC 110-130V/50,60Hz ST=23
3966010220 AC 220-240V/50,60Hz ST=23
D13 S
PECIAL SCREW
3616007000 20 SCM24H, 6.5x24
D15 BELT V
3616590220
1
M20.5, AGING 60Hz
3616590230 M21, AGING 50Hz
D16
GEAR MECHANISM
3617307610 1 GM-1300-KS6P0
D17 BOLT HEX 7341801511 4 6B-1, 8*15, MFZN
D18
PROTECTOR GEAR
3618301300 1 SBHG1, 1.6T
D19 CUSHION DOWN 3611502700 2 P.O.M, H=8mm
3964221211 AC 110V/60Hz W1D50CA012-S
3964821311
1
AC 120-127V/60Hz W1D50JA012-S
D20
MOTOR CONDENSER
3964321211 AC 220V/60Hz W1S50UA012
3964510411 AC 220V/50Hz W1D50VA012
3964610321 AC 230-240V/50Hz F33-2C-S
D22
PULLEY MOTOR AS
3618432000
1
ADC-12, DS=10, DP=48.5
60Hz
3618431900
ADC-12, DS=10, DP=53.0
50Hz
D23 BOLT HEX 7650804211 2 6B-1 8x42 S.P/W MFZN
To Next Page
