4
INSTALLATION IN STRUCTIONS
Location of washing machine
Check location where washing machine will be installed. Make sure you have everything
necessary for correct installation.
Proper installation is your responsibility.
• Do not place or store your washing machine below 0°C (32°F) to avoid any damage from
freezing.
• Install the washing machine on the horizontal solid floor.
Drain system
Never forget to install drain hose before operating your washing machine.
The packing box is opened, there are a drain hose.
If the washing machine is installed on an unsuitable floor, it
could make considerable noise, vibration and cause a
malfunction.
If washing machine is not level, adjust the front leg(A) up or
down for horizontal setting.
• Earthed electrical outlet(B) is required with 20cm ofbottom
back of washing machine cabinet(option).
• Hot and cold water faucets (C) must be within 1M of the
upper back of the washing machine cabinet and provide
water pressure 0.3kgf/cm² - 8kgf/cm² (2.94N/cm²-78.4cm²).
• Connect the drain hose to the drain outlet at
the back side of the washer.
• Connect the drain hose to the drain outlet at
the back side of the washing machine.
NOTES
• Carpet does not obstruct the openings for washing machines with ventilation openings in
the base.
Non-Pump Model Pump Model
Drain hose
Drain Outlet
Drain hose
UP
C
B
A
A
DOWN
