11. PA RT LIST
19
1 SHELF R 3017823200 1 2 2 GPPS 391/411
2 COVER CHILLED CASE 3011453400 1 1 1
3 CASE CHILD 3011163300 1 1 1 GPPS
4 COVER VEGTB CASE 3011453600 1 1 1 GPPS
5 CASE VEGTB 3011163400 2 2 2 GPPS
6 CASE ICING 3011163200 1 1 1 PP
7 CASE FD 3011115911 1 1 1 HIPS
8 CASE FB (411:CASE FC) 3011115310 2 2 - HIPS
3011115410 - - 2 HIPS
9 CASE FA 3011115202 1 1 1 HIPS
10 PLATE SHELF GLASS 3014547700 1 1 1 GLASS t4.0 OPTION
11 FRAME GLASS SHELF 3012202400 1 1 1 HIPS OPTION
12 FRAME C/CASE COVER 3012202500 1 1 1 HIPS OPTION
13 PLATE V/CASE COVER GLASS 3014547800 1 1 1 GLASS t4.0 OPTION
14 FRAME V/CASE COVER 3012202600 1 1 1 HIPS OPTION
15 BASE CONTROL PANEL PAGE 34 1 1 1 HIPS
16 PANEL CONTROL PAGE 34 1 1 1 ABS
17 CAP CONTROL PANEL A PAGE 34 1 1 1 SILICON RUBBER
18 SWITCH LAMP 3018111500 1 1 1 250V 0,25A
19 HARNESS LAMP SW 3012717020 1 1 1
20 INSULATOR MULTI DUCT 3013337100 1 - - F-PS
3013373000 - 1 1 F-PS
21 HARNESS THERMOSTAT 3012731500 1 1 1
22 THERMOSTAT 3018302200 1 1 1 250V 6A
23 COVER MULTI DUCT 3011452000 1 - - HIPS t2.0
3011452300 - 1 1 HIPS t2.0
24 SOCKET LAMP AS 3017903900 1 1 1 ASSY
25 LAMP 3013600700 1 1 1 230V 15W
26 WINDOW LAMP 3015503300 1 1 1 GPPS
27 KNOB R 3013401410 1 1 1 HIPS
28 HARNESS TIMER 3012731600 1 1 1
29 SWITCH DEF TIMER 3018115700 1 1 1
30 EVAPORATOR AS 3017045600 1 1 1 EVA+SUC PIPE
31 SWITCH BI-METAL 3018120600 1 1 1 250V 5A
32 HEATER D AS 3012807600 1 1 1 GLASS HEATER+FUSE TEMP
33 BRACKET FAN MOTOR 3010615600 1 1 1 PP
34 MOTOR FAN AS 3011604700 1 1 1 IS-231 1DWBF0
35 LOUVER F B 3018905500 1 1 - PP (411:HIPS)
3018905600 - - 1 PP (411:HIPS)
36 FAN 3011801400 1 1 1 ABS /100
37 FIXTURE FAN RING 3012005400 1 - - SUS304 t0.5
38 LOUVER F A 3018905300 1 1 - HIPS
3018905400 - - 1 HIPS
39 BUSHING FAN MOTOR 3010901800 2 2 2 NR
40 ASSY CAB URT 3010071031 1 - - ASSY
3010071041 - 1 - ASSY
3010071051 - - 1 ASSY
41 HINGE *T 3012908100 2 2 2 P/O+ZN t3.2
42 SPECIAL BOLT C 3016004900 10 10 10 M5xP0.89xL16 SWCH22A
43 CAP SCREW PAGE 34 1 1 1 PE-LD
44 CAP SCREW HOLE 3010920300 1 1 1 HIPS
45 SPECIAL WASHER HINGE 3016005500 3 3 3 S20C t1.0 13/7
46 SHAFT HI 3014903200 2 2 2
47 HINGE *M 3012908000 1 1 1 DIE CASTING
48 HINGE *U 3012908200 2 2 2 P/O+ZN t3.2
49 COVER CAB BRACKET PAGE 34 1 1 1 HIPS
50 FOOT ADJUSTING AS 3012101800 2 2 2 PP+SPECIAL BOLT
NO PART NAME PART CODE MODEL DESCRIPTION REMARK
361M 391M 411M
1. Parts list (ERF-361MM/391MM/411MM TYPE)
