12. PARTS LIST
12.1- ERF-364AR, ERF-394AR, ERF-414AR
364AR 394AR 414AR
1 SHELF R 3017823200 3 3 3 GPPS
2 COVER CHILLED CASE 3011453400 - 1 1 GPPS
3 CASE CHILD 3011163300 - 1 1 GPPS OPTION
3011163340 GPPS JUMBO
4 COVER VEGTB CASE 3011453600 1 1 1 GPPS
5 CASE VEGTB 3011163480 2 2 2 GPPS
6 CASE ICING 3011163200 1 1 1 PP
7 CASE FD 3011115940 1 1 1 HIPS
8 CASE FB 3011115310 2 2 - HIPS 364-394
CASE FC 3011115410 - - 2 HIPS 414
9 CASE FA 3011115230 1 1 1 HIPS
10 PLATE SHELF GLASS 3014547701 3 4 4 GLASS t4.0 OPTION
11 FRAME GLASS SHELF 3012202400 3 3 3 HIPS OPTION
12 FRAME C/CASE COVER 3012202500 - 1 1 HIPS OPTION
13
PLATE V/CASE COVER GLASS
3014547801 1 1 1 GLASS t4.0 OPTION
14 FRAME V/CASE COVER 3012202600 1 1 1 HIPS OPTION
15 BASE CONTROL PANEL COLOUR PAGE 1 1 1 HIPS
17 PCB MAIN AS 30143B6060 1 1 1 ERF-..4AR
18 HARNESS F PCB 3012718301 1 1 1
19 PCB F AS 30143B6160 1 1 1
20 WINDOWS LED 3015507400 1 1 1 SILICON RUBBER
21 PANEL CONTROL COLOUR PAGE 1 1 1 ABS
22 SWITCH LAMP 3018111500 1 1 1 250V 0,25A
23 WINDOW C/PANEL L/L 3015507220 1 1 1 ABS
24 SOCKET LAMP AS 3017903900 1 1 1 AC250V ASSY
25 COVER MULTI DUCT 3011451910 1 - - HIPS t2.0 364
3011452110 - 1 1 HIPS t2.0 394-414
26 INSULATOR MULTI DUCT 3013337000 1 - - F-PS 364
3013337200 - 1 1 F-PS 394-414
27 LAMP 3013600700 1 1 1 230V 15W
28 WINDOW LAMP 3015503300 1 1 1 GPPS
29 SENSOR R AS 3012731800 1 1 1
30 EVAPORATOR AS 3017044601 1 1 1 EVA+SUC PIPE+HEATER
31 HEATER DRAIN 3012806240 1 1 1
32 BRACKET FAN MOTOR 3010615600 1 1 1 PP
33 MOTOR FAN AS 3011804710 1 1 1 IS-23211DW18AG
34 LOUVER F B 3018905501 1 1 - PP 364-394
3018905601 - - 1 PP (414:HIPS) 414
35 FAN 3011801410 1 1 1 ABS /100
36 FIXTURE FAN RING 3012005400 1 - - SUS304 t0.5
37 LOUVER F A 3018913800 1 1 - HIPS 364-394
3018913900 - - 1 HIPS 414
38 BUSHING FAN MOTOR 3010901800 2 2 2 NR
39 ASSY CAB URT NO SPARE 1 - - ASSY
NO SPARE - 1 - ASSY
NO SPARE - - 1 ASSY
40 HINGE *T 3012908100 2 2 2 P/O+ZN t3.2
41 SPECIAL BOLT C 3016004900 10 10 10 M5xP0.89xL16 SWCH22A
42 CAP SCREW COLOUR PAGE 1 1 1 PE-LD
43 CAP SCREW HOLE 3010920300 1 1 1 HIPS
44 SPECIAL WASHER HINGE 3016005500 3 3 3 S20C t1.0 13/7
45 SHAFT HI 3014903200 2 2 2
46 HINGE *M 3012908001 1 1 1 DIE CASTING
47 HINGE *U 3012908201 2 2 2 P/O+ZN t3.2
48 COVER CAB BRACKET COLOUR PAGE 1 1 1 HIPS
49 FOOT ADJUSTING AS 3012101800 2 2 2 PP+SPECIAL BOLT
50 CAP DRAIN HOSE 3010919700 1 1 1 NBR
51 CASE VAPORY 3011162600 1 1 1 PP
DESCRIPTION REMARK
MODEL
NO PART NAME PART CODE
Daewoo Electronics 28
