43
REPLACEMENT OF MAIN COMPONENTS
H-3. R-Sensor of Refrigerator
Unscrew as illustrated below and pull-out the R-Sensor from the cover.
CCR-72TR
H-2. D-Sensor of Freezer (Evaporator Defrost Sensor)
Disassemble the D-Sensor from evaporator’s end plate.
D-Sensor
(Blue Color)
R-Sensor
(White Color)
Unscrew
