Daewoo FRN-U20DAI - 4-11. Function Summary

19
Element A/S Function
INPUT CONTROL OBJECT
CONTENTS REMARKS
Each button
Resistance of R-sensor Mid ON/OFF Point
“REF.TEMP”+ “FRZ.TEMP” 5 timesError display
“FRZ.TEMP”+ “FRZ.DOOR” OPEN/CLOSE 5 timesDemo function
“REF.TEMP”+ “FRZ.DOOR” OPEN/CLOSE 5 timesPull Down
“FRZ.TEMP” + “REF.TEMP” 5 timesForced Defrosting
1. All the modes are started “LOCK” mode (except “FILTER RESET” mode)
2. Element A/S Function
INPUT CONTROL OBJECT
CONTENTS REMARKS
Each button
Resistance of R-sensor Mid ON/OFF Point
“WATER/ICE” + “ICE MAKER LOCK” 5 timesIce maker test
“WATER/ICE”+ “RESET WATER FILTER” 5timesEEPROM clear
“FREEZER SET”+ “SUPER FREEZER” 5 timesError display
“REFRIGERATOR SET”+ “FREEZER SET”+ “WATER/ICE”5 timesPull Down
“REFRIGERATOR SET” + “WATER/ICE” 5 timesDemo function
Push “RESET WATER FILTER” for 3 secondsReset water filter
“FREEZER SET” + “REFRIGERATOR SET” 5 timesForced Defrosting
4-11. Summary of Function
4-11-1. FRS(N)-U20IA (Inner Control)
4-11. Summary of Function. 4-11-1. FRS(N)-U20DA (Front PCB)
