Daewoo FRS-T24FA - 2. ELECTRIC PARTS

2. ELECTRIC PARTS
1) COMPRESSOR
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 220 ~240/50
230 /50
(
EUROP
)
COMP MODEL
X HBL27YG-3 X HCL27YG-2 HPL27YG-4A HPL30YG-5 MK183Q-L2U
X 3952127R30 X 3957127R20 3956127R40 395S130R50 3956183D50
STARTING TYPE
X CSR X CSIR RSCR RSCR RSCR
2) RELAY
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 220~240 / 50 230 / 50
TYPE NAME
X 783SHB X 801SFB 419RHB 308NHB 265RHB
PART CODE
X 3018119370 X 3018118180 3018118131 3018119980 3018125210
PTC RESISTANCE
X
6.8
X
6.8
33 33 33
OVER LOAD
PART CODE
X 783SHB X 801SFB 419RHB 308NHB 265RHB
3) STARTING CAPACITOR
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 220~240 / 50 230 / 50
X 3016400100 X 3016400100 X X X
RATED VOLTAGE
X 200V X 200V X X X
RATED CAPACITANCE
X
100
X
100
XXX
4) RUNNING CAPACITOR
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 220~240 / 50 230 / 50
X 400EL15130 X X 3016401170 3016401920 3016401170
RATED VOLTAGE
X 230V X X 350V 400V 350V
RATED CAPACITANCE
X
10 §
XX
5§ 5§
5§
ASSY
PART CODE
PART CODE
PART CODE
5) F-FAN MOTOR
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/60 220~240 / 50 230 / 50
BL-2213DWFA-1
3015911300
REVOLUTION
DC 12V 2200RPM
6) R-FAN MOTOR
REFRIGERANT
R134a
VOLTAGE ( V/HZ)
100 /50,60 110 / 60 115,120/60 127/60 220/60 220~240 / 50 230 / 50
BL-2213DWRA-1
3015911400
REVOLUTION
DC 12V 2200RPM
TYPE NAME
TYPE NAME
PART CODE
PART CODE
SPECIFICATIONS
9
