OPERATION AND FUCTIONS
18. Home Bar (Home Bar Models Only) Heater
INPUT Control Object
None Comp.
CONTENTS REMARKS
It is linked with comp.
19. Control of Interior Lights
INPUT Control Object
Refrigerator Door
Freezer Door
Home-Bar Door
(Home Bar Models Only)
COMP
CONTENTS REMARKS
1) Control of Refrigerator Compartment Lights
R lights turn ON/OFF by R-door switch (ON/OFF).
10 minutes after sensing door open, the lights turn off automatically though
door close is not sensed.
2) Control of Freezer Compartment Lights
F lights turn ON/OFF by F-door switch (ON/OFF).
10 minutes after sensing door open, the lights turn off automatical ly though
door close is not sensed.
3) R-lights ON/OFF by Home Bar(Home Bar Models Only) door opening
R-lights turn ON for 1 minute after sensing HOME-BAR switch open.
(If the switch is pushed again within 1 minute, the light turns on another
1 minute.)
4) DISPENSER LAMP CONTROL
DISPENSER LAMP turns ON/OFF by DISPENSER SW.
Dispenser Lamp turns ON for 5 seconds after sensing switch close.
20. Demonstration Function
INPUT Control Object
"LOCK" button
"REFRIGERATOR SET." button
"SLEEP" button
COMP
F-FAN
R-FAN
CONTENTS REMARKS
1. Start
1) Set "LOCK ON" first.
2) Push "SLEEP" button 5 times while pushing "REF SET." button simultaneously.
2. Control
1) All other electrical components are OFF except for F-fan / R-fan.
2) Fan Control
DOOR OPEN FAN ON / DOOR CLOSE FAN OFF
3) Display : Normal mode (3sec.) SPEED(3sec. ) Super mode(3sec.)
Sleep mode (3sec.)
3. Stop or Termination
1) During Demo mode push "SLEEP" button 5 times while pushing "REF SET."
button simultaneously.
2) Power in again.
Silent mode(3sec.)
