5-3. Relay Function
1. Circuit Diagram
CONTENTS REMARKS
2. How it works;
#15≒12V
#14≒12V
#13≒12V
#12≒12V
#11≒12V
#10≒12V
#15≒12V
#14≒12V
#13≒12V
#12≒12V
#11≒12V
#10≒12V
#15≒0.7V
#14≒0.7V
#13≒0.7V
#12≒0.7V
#11≒0.7V
#10≒0.7V
#15≒0.7V
#14≒0.7V
#13≒0.7V
#12≒0.7V
#11≒0.7V
#10≒0.7V
OFF ConditionON Condition
#3≒0V#3≒5.0VRelay 3H/B Heater
IC8
#7≒0V
IC8
#7≒5.0VRelay 7Water valve (Dispenser)
#6≒0V#6≒5.0VRelay 6Water valve (Ice)
#5
≒0V#5≒5.0VRelay 5Dispenser-Solenoid
#4≒0V#4≒5.0V--
#9≒0V#9≒5.0VRelay 9Defrost-Heater
#8≒0V#8≒5.0VRelay 8Geared-Motor
#10≒0V#10≒5.0VRelay 10F-Lamp
#11≒0V#11≒5.0VRelay 11Cube-Solenoid
Relay 12
Relay 2
-
Control Mode
Method
IC7
IC ULN2004
Output pin
#12≒5.0V
#2≒5.0V
#1≒5.0V
MICOM Port
#12≒0V
#2≒0V
#1≒0V
MICOM Port
IC7
-
IC ULN2004
Output pin
Water Pipe Heater
R-Lamp
Control
IC1
(MICOM)
