Daewoo FRS-U20FF. - Page 50

50
Remove light cover screws.
Pull down smoothly the
bottom of light cover to
remove.
Remove the left housing.
Hold the end of F-Fan cover
and pull forward slowly.
Remove the screw cap on
the F-Louver A with a flat
tip driver.
Removing and replacing Freezer parts
Remove 3 screws of
F-Louver A.
Hold the end of F-Louver A
and pull forward slowly.
Remove the housing.
Remove the screw of
F-Return cover
and pull out cover.
Hold the end of F-Louver B
and pull forward slowly.
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
