Daewoo FRS-U20FF. - Page 55

55
* Remove screws
of light cover.
* Hold the bottom
of cover and pull
forward to remove.
①
②
③
* Change the light
bulbs.
(AC240V 25W)
Change the light bulb.
Start
Repair the R-door switch.
Check the R-door switch
connection and R-light socket.
Y
N
N
Y
Freezer light filament is
disconnected or breaking ?
Connection of R door
switch is OK ?
9-3-2. Disconnection / Breaking of Refrigerator Lights Wires
Change of F Lights Change of F Door Switch
Follow the reverse order
of disassembling after
changing the light.
①
②
* Insert a flat tip screw
driver into a gap of door
switch to pull forward.
* Disconnect the housing
and change the switch
for a new one.
Be careful when changing
the switch. F and R door
switch are different in type
and shape.
Follow the reverse order
of disassembling after
changing the switch.
