Daewoo FRS-U20IV - FUNCTIONS (Display - Inner Basic Model); Display Operation (Inner Basic Model)

1. Display ( Inner Basic Model )
a Temperature adjustment button for freezer compratment
b Temperature adjustment button for refrigerator compratment
2. Display Control
FUNCTIONS ( DISPLAY_Inner Basic Model )
FCP Cotrol
Temp. Display (Set Temp.) Initial Mode : Freezer / Refrigerator set medium ( 3 / 3 )
a
b
3. FRZ. SET button
1) Temperature control of freezer compartment
2) Initial power plug in : Medium ( 3 )
- Every time you press the FRZ. SET button, the setting temperature changes below order.
4. REF. SET button
1) Temperature control of refrigerator compartment
2) Initial power plug in : Medium ( 3 )
- Every time you press the REF. SET button, the setting temperature changes below order.
4
