56
6) When there is no convection motor.
When touching pad, oven lamp turns on.
Fan motor and turntable and cook indicator is display comes on.
* Cause : RELAY "1" does not operate.
CHECK METHOD
7) When the door is opened during operation, the count down timer does not stop.
CHECK METHOD
A
CN2
1
2
SECONDARY
INTERLOCK
SWITCH
C7
R10
C6
B
R2
1
MICOM
POINT
AB
STAGE
1) DOOR OPENED OPEN £«5VDC
2) DOOR CLOSED CLOSED GND
CHECK
METHOD REMEDY
NO.
1 Check the state (ON, OFF) of the secondary Replace secondary
Interlock switch by resistance measurement. interlock switch
A
MICOM
27
R7
Q4
B
D8
R32
+ 15V+ 15V
RELAY "1"
RY1
POINT
AB
STAGE
RELAY "1" ON £«5VDC GND
RELAY "1" OFF GND £«15VDC
