WIRING DIAGRAM(SLOW ACTING RELAY)
HIGH VOLTAGE TRANSFORMER
H.V.
CAPACITOR
H.V.
FUSE
H.V. DIODE
CL GM FMTM
POWER SUPPLY : SINGLE PHASE ~ ONLY
RD
RD
WH
FILTER ASS'Y
FUSE
L
N
N
GN
L
BR(BK) BL(WH) GE(GN)
PRIMARY INTERLOCK SWITCH(UPPER)
TIMER ASS'Y
SLOW ACTING RELAY ASS'Y
TIMER SWITCH
V.P.C
NO
COM
INTERLOCK MONITOR SWITCH
NC
BK
WH
BL
SECONDARY INTERLOCK SWITCH
WH
WH
WH
BK
SELECTION SWITCH 1
SELECTION SWITCH 2
SELECTION SWITCH ASS'Y
BK BK
GY
GY
GY
BL
HEATER
BL
BR BR
BR
BL
RD
NO NC
COM
GY GY BL
GY
MAGNETRON
1 3
2
M
RD
RD RD
NOTE RD : RED NOTE WH : WHITE NOTE BK : BLACK NOTE GN : GREEN NOTE BR : BROWNNOTE
OR : ORANGE BL : BLUE GY : GRAY GE : GREEN/YELLOW
CL : CAVITY LAMP FM : FAN(BLOWER) MOTOR GM : GEARED MOTOR TM : TIMER MOTOR V.P.C : VARIABLE POWER CONTROLLER
[CONDITION] DOOR : CLOSED TIMER : ON V.P.C. : HIGH
NOTE :
