28
2. Control Panel Ass’y
C-PANEL AS : 3516716070
REF NO. PART NAME PART CODE DESCRIPTION Q’TY REMARKS
B01 KNOB VPC 3513402680 ABS H-2938 XR-401 1
B02 CONTROL-PANEL
3516709860
ABS H-2938 XR-401
1
KOG-36A5
B03 SPRING FLAT 3515101600 SUS 301 T0.5 1
B04 COUPLER VPC KNOB 3517400500 POM 1
B05 SCREW TAPPING 7122401211 T2S TRS 4X12 PW MFZN 1
B06 COUPLER TIMER 3517400400 POM 1
B07 TIMER 3518203800 KN35MKD 24E-P 1
B08 SCREW TAPPING 7122401211 T2S TRS 4X12 PW MFZN 2
B09 KNOB 3513402580 ABS H-2938 XR-401 1
B10 LEVER DOOR OPEN 3513701420 ACETAL 1
B11 SPRING BUTTON 441G430171 SWP DIA. 0.7 1
B12 BUTTON DOOR OPEN
3516903650
ABS H-2938 XR-401 1
KOG-36A5
To Next Page
