5
1. Door seal - Door seal maintains the microwave
energy within the oven cavity and prevents
microwave leakage.
2. Cover Heater
3. Heating Element
4. Oven cavity
5. Safety interlock system
6. Metal Rack
7. Coupler - This fits over the shaft in the center of
the ovens cavity floor. This is to remain in the
oven for all cooking.
8. Roller guide - This must always be used for
cooking together with the glass cooking tray.
9. Glass cooking tray - Made of special heat
resistant glass. Food in a proper receptacle is
placed on this tray for cooking.
10. Door viewing screen - Allows viewing of food.
The screen is designed so that light can pass
through, but not the microwave.
11. Door hook - When the door is closed, it will
automatically shut off. If the door is opened
while the oven is operating, the magnetron will
immediately stop operating.
FEATURES DIAGRAM
