12
4. Method to reduce the gap between the door seal and the oven front surface.
(1) To reduce gap located on part ‘A’
Loosen two screws on stopper hinge top, and then
push the door to contact the door seal to oven front
surface.
Tighten two screws.
(2) To reduce gap located on part ‘B’
Loosen two screws on stopper hinge under, and then
push the door to contact the door seal to oven front
surface.
Tighten two screws.
(1) Remove the gasket door from door painting as.
(2) Remove the barrier screen inner from door painting as.
(3) Remove the door frame from door painting as.
(4) Remove the stopper hinge top from door painting as.
(5) Remove the spring and the hook.
(6) Remove the supporter barrier screen outer from door frame.
(7) Remove the barrier screen outer from door frame.
(8) Reverse the above steps for reassembly.
NOTE : A small gap may be acceptable if the microwave leakage does not exceed 4mW/cm
2
.
