Bill Of Materials
-23-
LED05 DLRF10SWCB LED CHIP HI-LRF10SWC
LED06 DLRF10SWCB LED CHIP HI-LRF10SWC
LED07 DLRF10SWCB LED CHIP HI-LRF10SWC
LED08 DLRF10SWCB LED CHIP HI-LRF10SWC
LED09 DLRF10SWCB LED CHIP HI-LRF10SWC
LED10 DLRF10SWCB LED CHIP HI-LRF10SWC
LED11 DLRF10SWCB LED CHIP HI-LRF10SWC
LED12 DLRF10SWCB LED CHIP HI-LRF10SWC
PW201 49590009S0 CONN WAFER 12505WR-05A00
PW202 49590001S0 CONN WAFER 12505WR-06A00
PW203 4859297920 CONN WAFER 12505WR-10A00
PW204 4859298020 CONN WAFER 12505WR-07A00
QC01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC03 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC04 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC05 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC06 T2SC2412KB TR CHIP 2SC2412K-T146-BR
ZZ290 PTMPMSG215 PCB MAIN MANUAL AS DLA-32C7LMBD
100 2193110012 SOLDER WIRE SAC3000 ø3.0MM (LFA3C0-W3.0)
200 2193110024 SOLDER WIRE SAC3005 ø1.6MM (LFA3-107-W1.6)
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
400 2291050312 FLUX SOLVENT S-3000
CE607 CEXF1H471V C ELECTRO 50V RSS 470MF (13X20) TP
CE611 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
HS301 4857032501 HEAT SINK AL EX BK L=26
HS501 4857032501 HEAT SINK AL EX BK L=26
IC701 1PC18LF452 IC MICOM PIC18LF452-I/P
JK250 4859118050 JACK PIN DPSE-9926S
JK270 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
L605 58C0000157 COIL CHOKE CH-470X
L606 58C0000157 COIL CHOKE CH-470X
M371 4853748800 RETA PCB NYLON 66
M372 4956800200 CLAMP WIRE WS-A-2-19
M381 4853829001 FRAME MAIN PCB SECC T=1.2 (A-2 : 32C1/32C3)
M381A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M381B 7178301052 SCREW TAPPTITE TT2 WAS 3X10 MFZN BK 3CR
M381C 7008300851 SCREW MACHINE WAS 3X8 MFZN 3CR
M381D 4856815900 CLAMP WIRE EGI T0.4+TUBE+PIE 3.2
M720 4853294100 BRKT POWER SW SECC 1T
M720A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
P201 485923162S CONN WAFER YW025-03 (STICK)
P202 4859201460 CONN D-SUB 9P SHRA0209011
P203 4959102340 JACK PHONE YKB21-5157
P204 4859201170 CONN OPTICAL SENSOR OJ107A-T050-SHS
P205 4859117950 JACK PIN DPSE-0415S
P206 4859113650 JACK PIN YSC02P-1200-10S (2P ST)
P207 4859113650 JACK PIN YSC02P-1200-10S (2P ST)
P208 4959200160 CONN D-SUB SHF-015-B111-22/BR2-J0.6
P401 4859284920 CONN WAFER SMW250-08
P601 4859284420 CONN WAFER SMW250-03
P602 4859284520 CONN WAFER SMW250-04
P703 4859231720 CONN WAFER YW025-04
P703A 4850709N12 CONNECTOR SMH250-09+SMH250-09+ULW=300
P705 4859285020 CONN WAFER SMW250-09
P705A 4850704S82 CONNECTOR YH025-04+YH025-04+ULW=300
Q760 TKTC3198Y- TR KTC3198Y
TU101 4859730730 TUNER DIGITAL TDVS-H707F (ATSC)
X101 5XJ25R00LD CRYSTAL QUARTZ HC-49/S 25.0MHZ 25PPM 20PF
X301 5XJ24R576E CRYSTAL QUARTZ HC-49/S 24.576MHZ 30PPM
X501 5XJ28R32GE CRYSTAL QUARTZ HC-49/S 28.322MHZ 30PPM 16PF
X601 5XE18R432E CRYSTAL QUARTZ HC-49/U 18.43200MHZ 30PPM
X701 5XE20R000E CRYSTAL QUARTZ HC-49/U 20.000MHZ 30PPM
ZZ200 PTMPJ2G215 PCB MAIN CHIP B AS DLA-32C7LMBD
CC101 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC102 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC103 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC104 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
LOC PART CODE PART NAME DESCRIPTION
CC105 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC106 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC108 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC109 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC110 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC111 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC112 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC113 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC114 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC115 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC116 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC117 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC118 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC120 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC121 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC123 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC124 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC127 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC128 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC134 HCQK240JBA C CHIP CERA 50V CH 24PF J 1608
CC135 HCQK240JBA C CHIP CERA 50V CH 24PF J 1608
CC150 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC151 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC152 HCBK105KBA C CHIP CERA 50V X7R 1MF K 1608
CC156 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC201 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC202 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC203 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC204 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC205 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC206 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC207 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC209 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC210 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC211 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC212 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC213 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC214 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC215 HCQK330JBA C CHIP CERA 50V CH 33PF J 1608
CC217 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC219 HCBK221KBA C CHIP CERA 50V X7R 220PF K 1608
CC241 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC242 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC251 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 1608
CC252 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 1608
CC253 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC254 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC271 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC301 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC302 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC303 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC304 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC305 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC306 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC307 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC308 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC309 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC310 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC311 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC312 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC313 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC314 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC315 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC316 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC317 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC318 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC319 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC320 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
LOC PART CODE PART NAME DESCRIPTION
