8. Bill Of Materials
-22-
ZZ100 48B5655D08 TRANSMITTER REMOCON R-55D08 (AAA)
ZZ110 PTACPWG215 ACCESSORY AS DLA-32C7LMBD
60 4850Q01210 BATTERY LR03 AAA ALKALINE
M212 4852176101 COVER BOTTOM ABS BK
M681 4856819300 CLAMP WIRE NYLON 66
M682 4856818710 CLAMP NYLON 6/6
M682A 7002401452 SCREW MACHINE TRS 4X14 MFZN BK 3CR
M683 2242070701 SHEET MICRO FIBER 180X180 T=0.7
M821 4858213803 BAG INSTRUCTION L.D.P.E TO.05X250X400(+20)
M861 48586230S1 MANUAL INSTRUCTION SL-230A,DLA-32C7LMBD,SPANISH
P801A 48599BM001 CORD POWER AS UL LP-31 LS-13 2.0M (LF)
ZZ120 PTBCSHG215 COVER BACK AS DLA-32C7LMBD
M211 4852177001 COVER BACK HIPS BK
M211A 4857818702 CLOTH BLACK FELT T0.7 L=350 W=15
M384 4853829200 FRAME WALL KIT SECC T=2.0
M384A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M593 4855945500 DECO SIDE AV PVC 0.3T
ZZ130 PTPKCPG215 PACKING AS DLA-32C7LMBD
M681 4856812400 BAND PP AUTO T1.1XW17MMXL770M
M801 4858071300 BOX CARTON DW-3
M811 485819DB00 PAD EPS
M822 4858219201 BAG P.E P.E FOAM T0.5X1100X950
M831 485CKPT045 PALLET 42" 1270 X 1150 X 120
ZZ140 PTCACAG215 CABINET AS DLA-32C7LMBD
JAK4A 4859005560 CABLE LVDS LPL:FMW1214A-31A+FH10001-30+42C1LMR=450
M201A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M201B 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M201C 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M201D 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M201E 7003401052 SCREW MACHINE BIN 4X10 MFZN BK 3CR
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M211B 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M211C 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M321 4853296800 BRKT STAND SECC T1.6
M321A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M322 4853296900 BRKT STAND BOX SECC T1.0
M322A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M322B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M382 4853829101 FRAME BAR SECC T=1.2 (A-2 : LPL PANEL)
M382A 7003401052 SCREW MACHINE BIN 4X10 MFZN BK 3CR
M382B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M491B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M541 4855421200 SPEC PLATE P.E 149X59
M720B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M721 4851957403 SHIELD CASE AS 7255702+5944603
M721A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M723 4857255902 SHIELD JACK AL 1100 T=1.0 (A-3 : SL-230D)
M723A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M723B 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
P601A 4850703N44 CONNECTOR SMH250-03+YRT205+YRT110+USW=600
P602A 4850704S80 CONNECTOR SMH250-04+YRT205+YRT110+USW=500
P803B 4850712S11 CONNECTOR 20022HS-12S+20022HS-12S+ULW=800
P803C 4850712S09 CONNECTOR 20022HS-12S+20022HS-12S+ULW=300
PM100 4850M13310 MODULE POWER FEL-3237A
SP01 4858318510 SPEAKER SP-45165F01C
SP01A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
SP02 4858318510 SPEAKER SP-45165F01C
SP02A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
V901 485LD00321 LCD PANEL LC320W01-SL01
ZZ200 PTFMSJG215 MASK FRONT AS DLA-32C7LMBD
M201 4852094901 MASK FRONT HIPS BK
M551 4855557201 DECO SENSOR GPPS
M551A 7178301052 SCREW TAPPTITE TT2 WAS 3X10 MFZN BK 3CR
M561 4855626000 MARK BRAND SILVER DIA-CUTTING(DOUBLE FACED TAPE),L=85,P=30
M590 4857943600 INDEX FILM PET 0.15T(KIMOTO 100NSH)
M591 4855945900 DECO PLATE ACRYL T2.0
ZZ210 PTSNSWG215 STAND AS DLA-32C7LMBD
M213 4852177301 COVER STAND BASE HIPS BK
LOC PART CODE PART NAME DESCRIPTION
M387 4853831001 FRAME STAND ABS BK
M387A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M521 4855219100 PLATE BASE STAND SECC T2.0
M521A 7115401051 SCREW TAPPING FLT 4X10 MFZN 3CR
M521C 4852937500 RUBBER BOTTOM CR60 BK PHI 18.0 X T 3.0
ZZ230 PTUNSWG215 PCB UNION AS DLA-32C7LMBD
100 2193110012 SOLDER WIRE SAC3000 ø3.0MM (LFA3C0-W3.0)
200 2193110024 SOLDER WIRE SAC3005 ø1.6MM (LFA3-107-W1.6)
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
400 2291050312 FLUX SOLVENT S-3000
IC290 1TS0P34838 IC PREAMP TSOP34838SJ
JP201 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
JP202 4859112850 JACK PIN DPSS-0173(3P ST)
LED1 DSPR39MVW- LED SPR-39MVW (DUAL)
M232 4852333201 PANEL CTRL HIPS BK
M491 4854964311 BUTTON CH ABS GY
M491A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M551 4855557201 DECO SENSOR GPPS
P201A 4850705N28 CONNECTOR 12505HS-05+12505TS+ULW=900
P202A 4850706S42 CONNECTOR 12505HS-06+12505HS-06+ULW=700
P203A 4850710N33 CONNECTOR 12505HS-10+12505HS-10+ULW=800
P204A 4850707S20 CONNECTOR 12505HS-07+12505HS-07+ULW=700
ZZ200 PTUNJ2G215 PCB UNION CHIP AS DLA-32C7LMBD
CC01 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC02 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC03 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC04 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC05 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC06 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC08 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC09 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC12 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC201 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 1608
CC202 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 1608
CC293 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
LC01 HLC479K02B L CHIP COIL 4.7UH MLF 1608
LC02 HLC479K02B L CHIP COIL 4.7UH MLF 1608
RC01 HRFT000-BA R CHIP 1/10 0 OHM 1608
RC02 HRFT000-BA R CHIP 1/10 0 OHM 1608
RC05 HRFT620JBA R CHIP 1/10 62 OHM J 1608
RC07 HRFT620JBA R CHIP 1/10 62 OHM J 1608
RC09 HRFT620JBA R CHIP 1/10 62 OHM J 1608
RC11 HRFT620JBA R CHIP 1/10 62 OHM J 1608
RC13 HRFT620JBA R CHIP 1/10 62 OHM J 1608
RC15 HRFT620JBA R CHIP 1/10 62 OHM J 1608
RC20 HRFT432JBA R CHIP 1/10 4.3K OHM J 1608
RC21 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
RC22 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
RC23 HRFT432JBA R CHIP 1/10 4.3K OHM J 1608
RC24 HRFT113JBA R CHIP 1/10 11K OHM J 1608
RC25 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
ZZ200 PTUNJRG215 PCB UNION RADIAL AS DLA-32C7LMBD
SW201 5S50101Z90 SW TACT THVV502GDA
SW202 5S50101Z90 SW TACT THVV502GDA
SW203 5S50101Z90 SW TACT THVV502GDA
SW204 5S50101Z90 SW TACT THVV502GDA
SW205 5S50101Z90 SW TACT THVV502GDA
SW206 5S50101Z90 SW TACT THVV502GDA
SW207 5S50101Z90 SW TACT THVV502GDA
ZZ200 PTUNJAG215 PCB UNION AXIAL AS DLA-32C7LMBD
ZZ200 PTUNJ1G215 PCB UNION CHIP A AS DLA-32C7LMBD
110 2193220010 SOLDER CREAM(PB-FREE) LST309-M(SN+3.0AG/0.5CU)
A001 4859833614 PCB UNION 189X189
IC01 1CA9557PWD IC CHIP CONVERTER PCA9557PW 16PIN TSSOP
LED01 DLRF10SWCB LED CHIP HI-LRF10SWC
LED02 DLRF10SWCB LED CHIP HI-LRF10SWC
LED03 DLRF10SWCB LED CHIP HI-LRF10SWC
LED04 DLRF10SWCB LED CHIP HI-LRF10SWC
LOC PART CODE PART NAME DESCRIPTION
1) DLA-32C7LMBD
