Daewoo LCD TV - Product Specification; Standard of Product

3. Product Specification
-5-
1) Standard of Product
Owing to our policy of continuous improvement, specifications may change.
Features DLA-32C7LMBD DLA-37C7LMBD DLA-42C7LMBD
LCD Panel Panel Model LC320W01-SL01 LC370WX01-SL01 LC420W05-SL01
Screen Size 81.28 cm 93.98 cm 106.68 cm
Aspect Ratio 16:9
Resolution 1366 x 768 (WXGA)
Pixel Pitch
170.25µm X 510.75µm 0.200mm X 0.600mm 0.227mm X 0.681mm
Contrast Ratio 3000 : 1 (MAX)
TV System Receiving NTSC, ATSC
System
LVDS Cable FL-X30SSL-HF
LVDS B+ +12V
Input Connector RF 75 Ohm Coaxial
S-Video / Video 2
Component RCA X 2
PC RGB D-Sub X 1
PC Audio 3.5 mm Mini-Jack
HDMI 1
Output SPDIF Optical- Jack
Connector Headphone X
Monitor - out 1
Sound Output Max. 10W
Power Module Model FEL-3237A FEL-3237A FEL-42C2
Power Max. 120 W 170 W 200 W
Consumption Power Source CA 110 - 240V~, 50/60Hz
Dimension Set Dimension
806 X 628.5 X 240 940 X 720 X 328.7 1037 X 791 X 329
(W x H x D) (with stand)
