Daewoo LM32L1 Service Manual

-36-
9. Service part list
ZZ100 48B6360C01 TRANSMITTER REMOCON R-60C01 (AAA)
ZZ110 PTACPWG490 ACCESSORY AS LP32L1B1LM
60 4850Q00910 BATTERY R03/NN
M211C 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M212 4852182601 COVER BOTTOM HIPS BK
M385A 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M681 4856819300 CLAMP WIRE NYLON 66
M683 2242070702 SHEET MICRO FIBER 150X180XT0.75
M821 4858219401 BAG INSTRUCTION L.D.P.E T0.05X280X470
M824 4858221000 BAG ACCESSORY T 0.5 X 70 X 110
M861 48586230K1 MANUAL INSTRUCTION KOREAN 32C1
M871 4858700000 CARD DTS-2998BT
PWC1 48599DM001 CORD POWER AS EU LP-33+LS-60=2.0M(LF)
ZZ120 PTBCSHG486 COVER BACK AS LX32L1B1LM
M211 4852182301 COVER BACK HIPS BK
M386 4853833101 FRAME WALL KIT ABS BK
M386A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
ZZ130 PTPKCPG469 PACKING AS LA32L1B1LM
M1F1 4851F03200 STAND AS 32L1
M214 4852182501 COVER FRAME STAND ABS+PMMA BK
M385 4853833601 FRAME STAND ABS BK
M801 4858075400 BOX CARTON DW-4 32L1
M811 485819EA00 PAD EPS
M822 4858215701 BAG P.E PE FOAM t0.5x1050x950
M841 6510030117 BAND PP AUTO T0.95XW17XL900M (10KG)
ZZ140 PTCACAG509 CABINET AS LM32L1B1SM
M131 485A117670 SHIELDRON 18X150X18(T)
M191 4851960701 SHIELD CASE AS 7257201+5950500
M191A 7178300852 SCREW TAPPTITE TT2 WAS 3X8 MFZN BK 3CR
M211A 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
M211D 4856019552 SCREW SPECIAL PLANE HEAD 3X8 MFZN BK 3CR
M321A 7173300852 SCREW TAPPTITE TT2 BIN 3X8 MFZN BK 3CR
M381A 7003400651 SCREW MACHINE BIN 4X6 MFZN 3CR
M381B 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
M382A 7003400651 SCREW MACHINE BIN 4X6 MFZN 3CR
M382B 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
M382C 4857802403 CLOTH BLACK FELT 80X10XT1.0
M541 4855421300 SPEC PLATE 150ART P/E FILM(148X58MM)
P100B 4850714S07 CONNECTOR 20022HS-14+20022HS-14+ULW=300
P502B 4859008560 CABLE LVDS SS:SMH200-30C+10030HS-30L+SLS00T=300
PM100 4850M011PW MODULE POWER FEL-3237VW
V901 485LDBA320 LCD PANEL LTA320AB02
ZZ200 PTFMSJG469 MASK FRONT AS LA32L1B1LM
M201 4852099001 MASK FRONT ABS+PMMA BK
M201A 4857821106 CLOTH BLACK FELT 360X10XT1.5
M561 4855626900 MARK BRAND SILVER DIA-CUTTING(LEG •’1.2 L=7.5)
M591 4855949701 DECO ABS BK
ZZ210 PTSPPWG469 SPEAKER AS LA32L1B1LM
P601A 4850703N51 CONNECTOR SMH250-03+YRT205+YRT110+USW=400
P602A 4850702N36 CONNECTOR SMH250-02+YRT205+YRT110+USW=400
SP01 48A8324510 SPEAKER SYSTEM SS-45165N02CR
SP02 48A8324500 SPEAKER SYSTEM SS-45165N02CL
ZZ290 PTMPMSG509 PCB MAIN MANUAL AS LM32L1B1SM
I503 1M24C32BN6 IC EEPROM M24C32WRN6
ICQ01 1R24FC6B— IC PREAMP R24FC6B
JP201 4959200160 CONN D-SUB SHF-015-B111-22/BR2-J0.6
JP202 4959102340 JACK PHONE SPJ-358H(3.5 STRAIGHT)
JP203 4859201460 CONN D-SUB 9P SHRA0209011
JP502 4859202821 CONN WAFER SMW200-30C
JPA02 4859117550 JACK PIN DPSE-0375S
JPA03 4859101780 JACK PIN YPJ-03S68 (3P SCART TYPE)
LOC PART CODE PART NAME DESCRIPTION
JPA04 4859101780 JACK PIN YPJ-03S68 (3P SCART TYPE)
JPA05 4859106840 JACK S-VHS SHAMD-1402-040B4
JPA07 4859201170 CONN OPTICAL SENSOR OJ107A-T050-SHS
CC512 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC513 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC515 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC518 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC520 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC523 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC525 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC528 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC530 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC531 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC536 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC537 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC538 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC539 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC540 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC541 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC542 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC543 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC544 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC545 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC546 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC547 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
CC548 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
CC549 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC550 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC551 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC552 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC553 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC554 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC555 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC556 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC557 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC558 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC559 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC560 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC561 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC562 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC563 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC564 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC566 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC567 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC568 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC569 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC570 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC571 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC572 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC573 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC577 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC601 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC602 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC605 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC606 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC607 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC614 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC617 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
CC618 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
CC621 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC622 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
LOC PART CODE PART NAME DESCRIPTION
LM32L1B1SM
9-1.BOM
