Daewoo LM32L1 Service Manual

-37-
Service part list
CC623 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC624 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC625 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC626 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC627 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC628 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
CC629 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
DCA29 D18S03015- VARISTOR CHIP AVLC18S03015
LC902 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC916 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC927 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC928 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC937 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA03 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA04 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA05 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA06 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA07 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA08 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA13 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA14 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA15 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCA16 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LCQ09 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
QC309 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC310 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC601 T2SC2412KB TR CHIP 2SC2412K-T146-BR
RC101 HRFT123JBA R CHIP 1/10 12K OHM J 1608
RC102 HRFT123JBA R CHIP 1/10 12K OHM J 1608
RC121 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC218 HRFT224JBA R CHIP 1/10 220K OHM J 1608
RC219 HRFT224JBA R CHIP 1/10 220K OHM J 1608
RC350 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC351 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC363 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC371 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC372 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC452 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC489 HRFT122JBA R CHIP 1/10 1.2K OHM J 1608
RC497 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC498 HRFT122JBA R CHIP 1/10 1.2K OHM J 1608
RC499 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC512 HRT5769FBA R CHIP 1/10 57.6 OHM F 1608
RC521 HRT5769FBA R CHIP 1/10 57.6 OHM F 1608
RC526 HRT5769FBA R CHIP 1/10 57.6 OHM F 1608
RC534 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC535 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC536 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC539 HRFT151JBA R CHIP 1/10 150 OHM J 1608
RC549 HRFT272JBA R CHIP 1/10 2.7K OHM J 1608
RC550 HRFT272JBA R CHIP 1/10 2.7K OHM J 1608
RC558 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC559 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC561 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC594 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC595 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC598 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC599 HRT5769FBA R CHIP 1/10 57.6 OHM F 1608
RC609 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC619 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC620 HRFT220JBA R CHIP 1/10 22 OHM J 1608
LOC PART CODE PART NAME DESCRIPTION
RC623 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
RC624 HRFT182JBA R CHIP 1/10 1.8K OHM J 1608
RC625 HRFT821JBA R CHIP 1/10 820 OHM J 1608
RC626 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC638 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC709 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC710 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC804 HRFT103FBA R CHIP 1/10 10K OHM F 1608
RC812 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RC913 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RCA01 HRFT224JBA R CHIP 1/10 220K OHM J 1608
SWQ04 5S50101Z90 SW TACT THVV502GDA
SWQ05 5S50101Z90 SW TACT THVV502GDA
SWQ06 5S50101Z90 SW TACT THVV502GDA
SWQ07 5S50101Z90 SW TACT THVV502GDA
X501 5XJX19R6JE CRYSTAL QUARTZ HC-49/S 19.6608MHZ 30PPM
ZZ200 PTMPJ1G509 PCB MAIN CHIP A AS LM32L1B1SM
A001 4859818693 PCB MAIN 189X234 K4V
C942 HCEJC470MC C CHIP ELECTRO 6.3V 47MF CS 5053
CA01 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CA02 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CC107 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC113 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC205 HCQK120JBA C CHIP CERA 50V CH 12PF J 1608
CC206 HCQK120JBA C CHIP CERA 50V CH 12PF J 1608
CC207 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
CC208 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC209 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC211 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC213 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC508 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC517 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
CC519 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC524 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC526 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC527 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC529 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC532 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC533 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC534 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC535 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC565 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC579 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
CC603 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC604 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC610 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC611 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC612 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC613 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC615 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC616 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC619 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
CC620 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
CC632 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
CC633 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC634 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
CC636 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC637 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC638 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC655 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC656 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
LOC PART CODE PART NAME DESCRIPTION

Daewoo LM32L1 Specifications

General

Brand	Daewoo
Model	LM32L1
Category	LCD TV
Language	English
