Daewoo LM32L1 Service Manual

-38-
Service part list
CC657 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC658 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC659 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC660 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC661 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC662 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC663 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC665 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC666 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC667 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC669 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC670 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC801 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC802 HCBK332KBA C CHIP CERA 50V X7R 3300PF K 1608
CC819 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CE901 HCEJC101MC C CHIP ELECTRO 6.3V 100MF LV 5055
CE902 HCEJC220MC C CHIP ELECTRO 6.3V 22MF CS 4052
CE907 HCEJC102ME C CHIP ELECTRO 6.3V 1000MF LV 1010
CE916 HCEJC220MC C CHIP ELECTRO 6.3V 22MF CS 4052
CE920 HCEJC101MC C CHIP ELECTRO 6.3V 100MF LV 5055
CE924 HCEJF471ME C CHIP ELECTRO 16V 470MF LV 8010
CE925 HCEJC102ME C CHIP ELECTRO 6.3V 1000MF LV 1010
CE927 HCEJC101MC C CHIP ELECTRO 6.3V 100MF LV 5055
CE928 HCEJC470MC C CHIP ELECTRO 6.3V 47MF CS 5053
CE930 HCEJF470MC C CHIP ELECTRO 16V 47MF CS 6352
CE931 HCEJC101MC C CHIP ELECTRO 6.3V 100MF LV 5055
CE932 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CE933 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CE947 HCEJC101MC C CHIP ELECTRO 6.3V 100MF LV 5055
CE948 HCEJC220MC C CHIP ELECTRO 6.3V 22MF CS 4052
CEQ01 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CT901 HCTBF220MB C CHIP TANTAL 16V 22MF M 3528
DC203 D18S03015- VARISTOR CHIP AVLC18S03015
DC204 D18S03015- VARISTOR CHIP AVLC18S03015
DC205 D18S03015- VARISTOR CHIP AVLC18S03015
DC206 D18S03015- VARISTOR CHIP AVLC18S03015
DC207 D18S03015- VARISTOR CHIP AVLC18S03015
DC901 DSK53B—-C DIODE CHIP SCHOTTKY SK53B
DCA19 D18S03015- VARISTOR CHIP AVLC18S03015
DCA20 D18S03015- VARISTOR CHIP AVLC18S03015
DZ901 DBZX848R2B DIODE CHIP ZENER BZX84C8V2
IC202 1M74HC14TC IC CHIP LOGIC M74HC14TTR
IC301 1CAT6341-Q IC CHIP HDMI SWITCH CAT6341CQ
IC302 124C02MN6D IC CHIP EEPROM M24C02-WMN6T
IC410 1K1A358F-C IC CHIP OP AMP KIA358F DUAL OP AMP FLP-8
IC501 1FL18541-Q IC CHIP VIDEO DECODER FLI8541
IC504 1W25X16VSD IC CHIP FLASH MEMORY W25X16VSSIG 16M-BIT
IC506 1P15V330S- IC CHIP VIDEO SWITCH P15V330S
IC507 1W9425G6DD IC CHIP DDR SDRAM W9425G6DH-5
IC601 1STV8317FQ IC CHIP AUDIO PROCESSOR STV8317F
IC602 1K1A7027TB IC CHIP RESET KIA7027AT 2.7V TSM TYPE
IC603 1TDA7491P- IC CHIP AUDIO AMP TDA7491P
IC604 1K1A7027TB IC CHIP RESET KIA7027AT 2.7V TSM TYPE
IC605 11LX232DTQ IC CHIP DRIVE ILX232DT
IC801 1MP2305DSB IC CHIP CONVERTOR MP2305DS
IC802 1Z1085S18D IC CHIP REGULATOR LDO AZ1085S-1.8TRE1 TO-263-3L
IC907 1MP1583—D IC CHIP CONVERTER MP1583DN
IC910 11L111733C IC CHIP REGULATOR IL1117-3.3 3.3V
IC917 11L111718C IC CHIP REGULATOR IL1117-1.8 1.8V
JK301 4859201360 CONN HDMI 51V019S-36WT-A1R
JK302 4859201360 CONN HDMI 51V019S-36WT-A1R
LOC PART CODE PART NAME DESCRIPTION
JK303 4859201360 CONN HDMI 51V019S-36WT-A1R
L601 HLC330KECE L CHIP COIL 33UH K 1280
L602 HLC330KECE L CHIP COIL 33UH K 1280
L603 HLC330KECE L CHIP COIL 33UH K 1280
L604 HLC330KECE L CHIP COIL 33UH K 1280
LC110 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC203 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC204 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC205 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC206 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC207 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC208 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC209 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC210 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LC517 HLC479J00A L CHIP COIL 4.7UH MLF2012
LC601 HLC100K02A L CHIP COIL 10UH MLF 2012
LC602 HLC100K02A L CHIP COIL 10UH MLF 2012
LC604 HLC100K02A L CHIP COIL 10UH MLF 2012
LC605 HLC100K02A L CHIP COIL 10UH MLF 2012
RC207 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RC208 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RC210 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC211 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC214 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC215 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC220 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC221 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC301 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC302 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC303 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC304 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC305 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC306 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC307 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC308 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC309 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC310 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC311 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC312 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC342 HRFT102JBA R CHIP 1/10 1K OHM J 1608
RC343 HRFT152FBA R CHIP 1/10 1.5K OHM F 1608
RC353 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC355 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC357 HRFT512JBA R CHIP 1/10 5.1K OHM J 1608
RC358 HRFT512JBA R CHIP 1/10 5.1K OHM J 1608
RC360 HRFT474JBA R CHIP 1/10 470K OHM J 1608
RC361 HRFT474JBA R CHIP 1/10 470K OHM J 1608
RC364 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC501 HRFT330JBA R CHIP 1/10 33 OHM J 1608
RC503 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC504 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
RC506 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC507 HRT2490FBA R CHIP 1/10 249 OHM F 1608
RC508 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC514 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC515 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC518 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC520 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC522 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC523 HRFT220JBA R CHIP 1/10 22 OHM J 1608
RC524 HRFT220JBA R CHIP 1/10 22 OHM J 1608
LOC PART CODE PART NAME DESCRIPTION
