Daewoo LM32L1 Service Manual

-39-
Service part list
RC528 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC529 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC530 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC531 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC532 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC533 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC540 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC541 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
RC548 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
RC551 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC553 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC556 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC557 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC562 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC566 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC579 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC580 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
RC581 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC582 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC583 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC584 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RC585 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RC586 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RCQ02 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
RCQ03 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RCQ04 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RCQ05 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
RCQ06 HRFT432JBA R CHIP 1/10 4.3K OHM J 1608
RCQ07 HRFT113JBA R CHIP 1/10 11K OHM J 1608
RCQ08 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
RCQ09 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
RCQ15 HRFT000JBA R CHIP 1/10 0 OHM J 1608
VA312 D18S03015- VARISTOR CHIP AVLC18S03015
JPA08 4859118450 JACK PIN RCA-346P 3P ANGLE
LED01 DLW47B3311 LED LAMP W47B3311M (SINGLE BLUE)
M111 4851117402 PANEL AV AS 2335401+5950802
M321 4853299501 BRKT BUTTON ABS BK
M371 4853748800 RETA PCB NYLON 66
M372 4956800200 CLAMP WIRE WS-A-2-19
M381 4853834900 FRAME SIDE T SECC T1.0
M382 4853835000 FRAME SIDE B SECC T1.0
M383 4853835100 FRAME SUPPORT R SECC T1.0
M383A 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M384 4853835200 FRAME SUPPORT L SECC T1.0
M384A 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M384B 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M384C 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M491 4854965801 BUTTON CH ABS BK
M551 4855558711 DECO SENSOR GPPS GY
M592 4855949600 DECO LED GPPS
P601 4959260620 CONN WAFER SMAW250-03
P602 4959260820 CONN WAFER SMAW250-02
P801 4959203820 CONN WAFER SMW250-15
P801B 4850715S06 CONNECTOR SMH250-15+SMH250-15+ULW=200
P901A 4859299921 CONN WAFER 20017WR-08A
P901B 4850708S32 CONNECTOR 20017HR-08+12505HS-08+2385=400
P902A 4859299720 CONN WAFER 20017WR-05A
P902B 4850705N50 CONNECTOR 20017HS-05+12505HS-05+2835=400
P903A 4859290520 CONN WAFER 20017WR-04A
P903B 4850704N48 CONNECTOR 20017HS-04+12505HS-04+USW=800
TU01 4859731730 TUNER VARACTOR TAFT-W013D(PA-2-A-D)
LOC PART CODE PART NAME DESCRIPTION
XC601 5XJ27R00AE CRYSTAL QUARTZ HC-49/S 27.000MHZ 10PF 30PPM
ZZ200 PTMPJ2G509 PCB MAIN CHIP B AS LM32L1B1SM
CC202 HCQK120JBA C CHIP CERA 50V CH 12PF J 1608
CC203 HCQK120JBA C CHIP CERA 50V CH 12PF J 1608
CC204 HCQK120JBA C CHIP CERA 50V CH 12PF J 1608
CC210 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC212 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC214 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC215 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC216 HCFD105ZBA C CHIP CERA Y5V 10V 1MF Z 1608
CC301 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC302 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC303 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC304 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC305 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC306 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC307 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC308 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC309 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC310 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC311 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC312 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC313 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC450 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC451 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC452 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC501 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC502 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC503 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC504 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC505 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC506 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC507 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC509 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC510 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC511 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC630 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC631 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC635 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC639 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC640 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC641 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC642 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC643 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC644 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC645 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC646 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC647 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC648 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC649 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC650 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC651 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC652 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC654 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
CC664 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC668 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC803 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC804 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC805 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC815 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC835 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
LOC PART CODE PART NAME DESCRIPTION
