-48-
Circuit Diagram
DIFFERENT PARTS FOR SL-602M
No. LOC. Part Name LM32L1B1SM LM32L1B1LM LM37L1B1LM LM42L1B1LM
1 P502B CABLE LVDS SS:SMH200-30C+10030HS-30L+SLS00T=300 LPL:SMH200-30C+10030HS-30L2B+SLS00=300 <-- <--
2 RC560 R CHIP NC 1/10 10K OHM J 1608 <-- <--
3 RC566 R CHIP 1/10 10K OHM J 1608 NC NC NC
4 RC707 R CHIP NC 1/10 0 OHM J 1608 <-- <--
5 RC710 R CHIP 1/10 100 OHM J 1608 NC NC NC
6 V901 LCD PANEL LTA320AB02 LC320WXN-SAC1 LC370WXN-SAB1 LC420WXN-SAB1
7 PM100 MODULE POWER FEL-3237VW <-- <-- FEL-4247VW
DIFFERENT PARTS FOR SL-602P
No. LOC Part Name LM32L1B1SM LP32L1B1SM LP32L1B1LM LP37L1B1LM LP42L1B1LM
1 CA03 C CHIP ELECTRO NC 16V 10MF MV 4052 <— <— <—
2 CA04 C CHIP ELECTRO NC 16V 10MF MV 4052 <— <— <—
3 CC514 C CHIP CERA NC 50V X7R 0.1MF K 1608 <— <— <—
4 CC516 C CHIP CERA NC 25V X7R 0.22MF K 1608 <— <— <—
5 CC580 C CHIP CERA NC 50V X7R 0.1MF K 1608 <— <— <—
6 CC581 C CHIP CERA NC 50V X7R 0.1MF K 1608 <— <— <—
7 CC608 C CHIP CERA NC Y5V 10V 1MF Z 1608 <— <— <—
8 CC609 C CHIP CERA NC Y5V 10V 1MF Z 1608 <— <— <—
9 CCA15 C CHIP CERA NC 50V CH 1000PF J 1608 <— <— <—
10 CCA19 C CHIP CERA NC 50V CH 1000PF J 1608 <— <— <—
11 CCA26 C CHIP CERA NC 50V CH 1000PF J 1608 <— <— <—
12 CCA30 C CHIP CERA NC 50V CH 1000PF J 1608 <— <— <—
13 CE102 C CHIP ELECTRO NC 6.3V 220MF LV 8065 <— <— <—
14 CE608 C CHIP ELECTRO NC 16V 10MF MV 4052 <— <— <—
15 CE609 C CHIP ELECTRO NC 16V 10MF MV 4052 <— <— <—
16 DCA06 VARISTOR CHIP NC AVLC18S03015 <— <— <—
17 DCA08 VARISTOR CHIP NC AVLC18S03015 <— <— <—
18 DCA09 VARISTOR CHIP NC AVLC18S03015 <— <— <—
19 DCA10 VARISTOR CHIP NC AVLC18S03015 <— <— <—
20 DCA11 VARISTOR CHIP NC AVLC18S03015 <— <— <—
21 DCA12 VARISTOR CHIP NC AVLC18S03015 <— <— <—
