Daewoo LM32L1 Service Manual

-49-
DIFFERENT PARTS FOR SL-602P
No. LOC Part Name LM32L1B1SM LP32L1B1SM LP32L1B1LM LP37L1B1LM LP42L1B1LM
22 DCA13 VARISTOR CHIP NC AVLC18S03015 <— <— <—
23 DCA14 VARISTOR CHIP NC AVLC18S03015 <— <— <—
24 DCA23 VARISTOR CHIP NC AVLC18S03015 <— <— <—
25 DCA25 VARISTOR CHIP NC AVLC18S03015 <— <— <—
26 DCA26 VARISTOR CHIP NC AVLC18S03015 <— <— <—
27 DCA28 VARISTOR CHIP NC AVLC18S03015 <— <— <—
28 JPA03 JACK PIN YPJ-03S68 (3P SCART TYPE) NC NC NC NC
29 JPA03 JACK SCART NC DSSM-0378 STR <— <— <—
30 JPA04 JACK PIN YPJ-03S68 (3P SCART TYPE) NC NC NC NC
31 JPA04 JACK SCART NC DSSM-0378 STR <— <— <—
32 LCA09 F CHIP FERRITE BEAD NC 40 OHM MMZ 2012S <— <— <—
33 LCA10 R CHIP NC 1/10 0 OHM J 2012 <— <— <—
34 LCA11 R CHIP NC 1/10 0 OHM J 2012 <— <— <—
35 LCA12 R CHIP NC 1/10 0 OHM J 2012 <— <— <—
36 P100B CONNECTOR 20022HS-14+20022HS-14+ULW=300 <— <— NC 20022HS-14+20022HS-14+ULW=300
37 P502B LVDS CABLE SS:SMH200-30C+10030HS-30L+SLS00T=300 <— LPL:SMH200-30C+10030HS-30L2B+SLS00=300 <— <—
38 P801C CONNECTOR NC NC NC 20022HS-14+20022HS-14+ULW=300 NC
39 P601A CONNECTOR SMH250-03+YRT205+YRT110+USW=400 <— <— <— NC
40 P602A CONNECTOR SMH250-02+YRT205+YRT110+USW=400 <— <— <— NC
41 PM100 MODULE POWER FEL-3237VW FEL-3237VN <— <— FEL-4247VN
42 QC101 TR CHIP NC 2SC2412K-T146-BR <— <— <—
43 QCA01 TR CHIP NC 2SC2412K-T146-BR <— <— <—
44 RC103 R CHIP NC 1/10 4.7K OHM J 1608 <— <— <—
45 RC509 R CHIP NC 1/10 22 OHM J 1608 <— <— <—
46 RC510 R CHIP NC 1/10 22 OHM J 1608 <— <— <—
47 RC511 R CHIP NC 1/10 22 OHM J 1608 <— <— <—
48 RC513 R CHIP NC 1/10 22 OHM J 1608 <— <— <—
49 RC560 R CHIP NC NC 1/10 10K OHM J 1608 <— <—
50 RC566 R CHIP 1/10 10K OHM J 1608 <— NC <— <—
51 RC601 R CHIP NC 1/10 220 OHM J 1608 <— <— <—
52 RC602 R CHIP NC 1/10 0 OHM J 1608 <— <— <—
53 RC604 R CHIP NC 1/10 220 OHM J 1608 <— <— <—
54 RC605 R CHIP NC 1/10 0 OHM J 1608 <— <— <—
55 RC707 R CHIP NC NC 1/10 0 OHM J 1608 <— <—
56 RC710 R CHIP 1/10 100 OHM J 1608 <— NC <— <—
57 RCA08 R CHIP 1/10 0 OHM J 1608 1/10 10K OHM J 1608 <— <— <—
58 RCA09 R CHIP NC 1/10 30K OHM J 1608 <— <— <—
59 RCA16 R CHIP NC 1/10 75 OHM J 1608 <— <— <—
60 RCA17 R CHIP NC 1/10 30K OHM J 1608 <— <— <—
