ExplodedViewandMechanicalParts List
No. PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS
1 PANEL FRONT 9CD0322500 HIPS 1
2 KNOB VR 9CD1370900 HIPS 1
3 KNOB TUNING 9CD1371000 HIPS 1
4 STOPPER 9CD5700700 HIPS 1
5 WINDOW LCD 9CD1628600 ACRYL 1
6 KNOB REC 9CD1371100 HIPS 1
7 KNOB FUNCTION 9CD1370800 HIPS 1
8 DECO FRONT L 9CD10195L0 HIPS 1
9 DECO FRONT R 9CD10195R0 HIPS 1
10 BRACKET CABINET 9CD2421200 SECC T1.0 2
11 REFLECTOR LED L 9CD22006L0 HIPS 1
12 REFLECTOR LED R 9CD22006R0 HIPS 1
13 CUSHION FOOT 9CD4
212500 POPON MX-48HF Φ10*T3.0 2 NC-8015/16 4PCS
14 SHEET DIFFUSION 9CD9603100 PE 0.15T 1
15
9CD1621600 PMMA 1
16 GUIDE LCD 9CD2509500 HIPS WHITE 1
17 FRONT PCB AS FCDC00550X NC-8011/8015/8016DE 1
18 SCREW MACHINE 7003263511 M2.6X3.5 1
19 GEAR PVC 9CD2702600 ABS 1
20 PIN GEAR 9CD3501700 PW 1
21 GEAR IDLE 9CD2702700 ABS 1
22 TUNER PCB AS FCDC005700 NC-8011/8015/8016DE 1
23 NUT 7391500011 M5X0.8 1
24 USB & AUX PCB AS FCDC005510 NC-8011/8015/8016DE 1
25 AM ANT PCB AS FCDC005509 NC-8011/8015/8016DE 1
26 SW VOLTAGE SELE 5S30102377-1 ZH-06-01 1 ONLY
FOR TOSHIBA
27 HEAT SINK 15 9CD4415500 AL T2.0 1 NC-8011DE
28 MAIN PCB AS FCDC00540X NC-8011 1
29 BRACKET HEAT TR 9CD2413901 STS T0.4 1
30 PLATE MICA 9CD0910600 WHITE MICA 25X30mm 1 NC-8011DE
31 POWER TRANS 5TP0066F78 EI=66X30 127V/230V 60/50Hz 1 NC-8011DE
No. PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS
32 CHASSIS BOTTOM 9CD0617900 HIPS 1
33 POWER PCB AS FCDC005000 NC-8011DE 1
34 CD (MP3) PCB AS FCDC005600 NC-8011/8015/8016DE 1
35 BRACKET CD DECK 9CD2421601 HIPS 1
36-1 CD- PICK UP 9CD6014830 R800 1 RICHLY
36-2 CD- PICK UP 9CD6014200 DA11VZ SANYO 1 SANYO
37 CD DECK 9CD6016800 8210D 1 ASA
38 COVER SIDE L 9CD04262L0 HIPS 1
39 COVER SIDE R 9CD04262R0 HIPS 1
40-1 COVER BACK 9CD0426100 HIPS 1 NC-8011DE
40-2 COVE
R BACK 9CD0426110 HIPS 1 NC-8015/16DE
41 COVER TOP 9CD0426000 HIPS 1
42 DOOR CD 9CD1819800 HIPS 1
43 AMP PCB AS FCDC00540X NC-8015/8016DE 1
44 HEAT SINK AMP 9CD4415610 AL EXT 1 NC-8015DE
45 SMPS PCB AS FCDC005800 NC-8015/8016DE 1
46 CHASSIS BOTTOM 9CD0618000 SECC T1.0 1 NC-8015/16DE
47 HEAT SINK AMP 9CD4415710 AL EXT 1 NC-8016DE
48 BRACKET PCB AMP 9CD2422400 HIPS 1 NC-8015/16DE
49 HOLDER AC CORD 9CD2303300 HIPS 1 NC-8015/16DE
50 SUPPORT PCB 12 9CD25074
01 HIPS 3 NC-8015/16DE
51 AC CORD F736909021 2X0.75mm2 L=1.85M 1
52 SHIELD SMPS PCB 9CD3305600 SPTE T0.3 1
S1 SCREW TAPPTITE 7173261011 TT2 BIN 2.6X10 MFZN 20
S2 SCREW TAPPTITE 7173301011 TT2 BIN 3X10 MFZN 11
S3 SCREW TAPPTITE 7173300811 TT2 BIN 3X8 MFZN 4 NC-8015/16 13PCS
S4 SCREW WASHER 9CD3102400 TT2 WAS 3X10+D14 MFZN 3 NC-8011 4PCS
S5 SCREW TAPPTITE 7173301211 TT2 BIN 3X12 BK 23
S6 SCREW TAPPTITE 7173401211 TT2 BIN 4.0X12 MFZN 4 ONLY NC-8011DE
S7 SCREW TAPPTITE 7173301411 TT2 BIN 3X14 MFZN 3 ONLY NC-8015/8016DE
