Daewoo RL-211W - Electrical Part List

Electrical Parts List
16
RL-211W RL-212W RL-211W RL-212W
1 AS MAIN PCB 9CDC060600
9CDC061800
O 72 C ELECTRO CE620 CEXF1C101V 16V RSS 100MF (6.3X11) TP O O
2 AS MAIN PCB O 73 C ELECTRO CE621 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O
3 PCB MAIN B001 9CD6586100 247X197X1.6T O O 74 C ELECTRO CE622 CEXF1C101V 16V RSS 100MF (6.3X11) TP O O
4 C CERA CC001 CCZB1H102K 50V B 1000PF K (AXIAL) O O 75 C ELECTRO CE625 CEXF1E470V 25V RSS 47MF (5X11) TP O O
5 C CERA CC002 CCZF1H103Z 50V F 0.01MF Z O O 76 C ELECTRO CE801~802 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O
6 C CERA CC004 CCZF1H103Z 50V F 0.01MF Z O O 77 C ELECTRO CE803~804 CEXF1C102V
CEXF1E102V
16V RSS 1000MF (10X20) O
7 C CERA CC006 CCZF1H103Z 50V F 0.01MF Z O O 78 C ELECTRO CE803~804 25V RSS 1000MF (10X22) O
8 C CERA CC102 CCZF1H103Z 50V F 0.01MF Z O O 79 C ELECTRO CE805 CEXF1H100V 50V RSS 10MF (5X11) TP O O
9 C CERA CC103 CCZF1H104Z HIKF 50V 0.1MF Z AXIAL O O 80 C ELECTRO CE806 CEXF1E330V 25V RSS 33MF (5X11) TP O O
10 C CERA CC104 CZCH1H150J 50V CH 15PF J (AXIAL) O O 81 C ELECTRO CE807 CEXF1H100V 50V RSS 10MF (5X11) TP O O
11 C CERA CC105 CZCH1H820J CH 50V 82PF J AXL 52MM O O 82 C ELECTRO CE808 CEXF1H101V 50V RSS 100MF (8X11.5) TP O O
12 C CERA CC201~102 CCZF1H473Z 50V F 0.047MF Z O O 83 C ELECTRO CE809 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
13 C CERA CC203 CCZB1H391K 50V B 390PF K (AXIAL) O O 84 C ELECTRO CE902 CEYF1V102V 35V RSS 1000MF (13X25) O O
14 C CERA CC205 CCZB1H562K 50V B 5600PF K(AXIAL) O O 85 C ELECTRO CE909 CEXF1V222V 35V RSS 2200MF 16X31.5
CEXF1H222V 50V RSS 2200MF 16X35
O
15 C CERA CC206 CCZF1H473Z 50V F 0.047MF Z O O 86 C ELECTRO CE909 O
16 C CERA CC207 CCZF1H104Z HIKF 50V 0.1MF Z AXIAL O O 87 C ELECTRO CE911~915 CEXF1H100V 50V RSS 10MF (5X11) TP O O
17 C CERA CC209 CCZF1H473Z 50V F 0.047MF Z O O 88 C ELECTRO CE913 CEXF1C331V 16V RSS 330MF (8X11.5) TP O O
18 C CERA CC210~212 CCZF1H103Z 50V F 0.01MF Z O O 89 FILTER CERA CF001~002 5PE107MJA- SFE 10.7MHZ RED O O
19 C CERA CC214~215 CCZB1H562K 50V B 5600PF K(AXIAL) O O 90 FILTER CF201 5PPCFAZ077 PCFAZ077 O O
20 C CERA CC216~217 CCZB1H682K 50V HIKB 6800PF K AXIAL O O 91 C MYLAR CM201~202 CMXM1H153J 50V 0.015MF J (TP) O O
21 C CERA CC251 CCZF1H104Z HIKF 50V 0.1MF Z AXIAL O O 92 C MYLAR CM401~402 CMXM1H104J 50V 0.1MF J O O
22 C CERA CC252 CCZF1H103Z 50V F 0.01MF Z O O 93 C MYLAR CM403~404 CMXM1H272J 50V 2700PF J O O
23 C CERA CC253~254 CCZB1H102K 50V B 1000PF K (AXIAL) O O 94 C MYLAR CM405~408 CMXM1H104J 50V 0.1MF J O O
24 C CERA CC255 CZCH1H360J CH 50V 36PF J AXIAL O O 95 C MYLAR CM601~602 CMXM1H562J 50V 5600 PF J O O
25 C CERA CC256 CZCH1H330J CH 50V 33PF J AXIAL 52MM O O 96 C MYLAR CM603 CMXM1H222J 50V 2200PF J O O
26 C CERA CC257 CCZF1H103Z 50V F 0.01MF Z O O 97 C MYLAR CM605~606 CMXM1H223J 50V 0.022MF J O O
27 C CERA CC259 CCZF1H103Z 50V F 0.01MF Z O O 98 C MYLAR CM611~612 CMXM1H472J 50V 0.0047MF J O O
28 C CERA CC270 CCZB1H331K 50V B 330PF K (AXIAL) O O 99 C MYLAR CM803~804 CMXM1H473J 50V 0.047MF J O O
29 C CERA CC272 CCZF1H103Z 50V F 0.01MF Z O O 100 CONN PIN CN401 9736407800 53095-1010 10PIN ANGLE O O
30 C CERA CC276~277 CZCH1H220J 50V CH 22PF J (AXIAL) O O 101 CONN PIN CN402 9736407800 53095-1010 10PIN ANGLE O O
31 C CERA CC290 CCZF1H104Z HIKF 50V 0.1MF Z AXIAL O O 102 CONN AS CN601 9728814200
UL2547+1533 #28 6P+7P SHIELD
1
OO
32 C CERA CC492~493 CZCH1H101J CH 50V 100PF J AXL 52MM O O 103 CONN WAFER CW101 9CD6258800 2P S2B-XH-A O O
33 C CERA CC494 CCZF1H473Z 50V F 0.047MF Z O O 104 CONN AS CW509 9728813500 6P 100MM P=2.5 BOARD-IN O O
34 C CERA CC601~602 CCXB1H122K 50V B 1200PF K (TAPPING) O O 105 CONN AS CW601 9728814200
UL2547+1533 #28 6P+7P SHIELD
1
OO
35 C CERA CC603~604 CCZB1H221K 50V B 220PF K (AXIAL) O O 106 CONN AS CW901 9728813200
9728813300
UL1617 #22 5P P=2.5X140M O
36 C CERA CC613~614 CCZB1H221K 50V B 220PF K (AXIAL) O O 107 CONN AS CW901 UL1617 #22 6P P=2.5X140M O
37 C CERA CC615~616 CCZB1H181K 50V B 180PF K (AXIAL) O O 108 DIODE D402 DZN4148--- 1N4148 AUTO 52MM O O
38 C CERA CC617~620 CCZB1H102K 50V B 1000PF K (AXIAL) O O 109 DIODE D800~803 DZN4148--- 1N4148 AUTO 52MM O O
39 C CERA CC625 CCZF1H223Z 50V F 0.022MF Z O O 110 DIODE D905 DZN4148--- 1N4148 AUTO 52MM O O
40 C CERA CC801~802 CCZB1H102K 50V B 1000PF K (AXIAL) O O 111 ZENER DIODE DZ801 DZTZ5R1A-- 5.1V O O
41 C CERA CC803~804 CCZF1H103Z 50V F 0.01MF Z O O 112 IC IC201 1LA1833N-- LA1833N O O
42 C CERA CC805 CCZF1H223Z 50V F 0.022MF Z O O 113 IC IC202 1LC72131D- LC72131D O O
43 C CERA CC806 CCZF1H473Z 50V F 0.047MF Z O O 114 IC REGULATOR IC205 1KA78L05AZ KA78L05AZ O O
44 C CERA CC809~810 CCZF1H473Z 50V F 0.047MF Z O O 115 IC IC270 1LC72723M- LC72723M O O
45 C CERA CC901~905 CCZF1H223Z 50V F 0.022MF Z O O 116 IC FUNCTION IC401 1PT2314--- PT2314 O O
46 C ELECTRO CE001 CEXF1E470V 25V RSS 47MF (5X11) TP O O 117 IC AUDIO IC601 1TA8142AP- TA8142AP O O
47 C ELECTRO CE101 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 118 IC IC602 1UPC1330HA UPC1330HA O O
48 C ELECTRO CE102 CEXF1C221V 16V RSS 220MF (8X11.5) TP O O 119 IC IC800 1TDA7499-- TDA7499 O
49 C ELECTRO CE201 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O 120 IC IC800 1TDA7265-- TDA7265 O
50 C ELECTRO CE202 CEXF1H100V 50V RSS 10MF (5X11) TP O O 121 IC IC901 1L4959---- L4959 O O
51 C ELECTRO CE203 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O 122 JACK ANT J001 9736324900 IF-A O O
52 C ELECTRO CE204 CEXF1E330V 25V RSS 33MF (5X11) TP O O 123 JACK H/P J401 9736323200 HTJ035-13AB GOLD O O
53 C ELECTRO CE206 CEXF1H109V 50V RSS 1MF (5X11) TP O O 124 JACK RCA J490 9CD6313700 S-436P O O
54 C ELECTRO CE207 CEXF1H478V 50V RSS 0.47MF (5X11) TP O O 125 JACK SPEAKER J800 9736320500 CJ-9007-040 O O
55 C ELECTRO CE208 CEXF1H109V 50V RSS 1MF (5X11) TP O O 126 WIRE JUMPER JW201 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
56 C ELECTRO CE209~210 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 127 WIRE JUMPER JW203 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
57 C ELECTRO CE211 CEXF1H339V 50V RSS 3.3MF (5X11) TP O O 128 WIRE JUMPER JW204 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO O O
58 C ELECTRO CE214 CEXF1E470V 25V RSS 47MF (5X11) TP O O 129 WIRE JUMPER JW205 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
59 C ELECTRO CE270~271 CEXF1H100V 50V RSS 10MF (5X11) TP O O 130 WIRE JUMPER JW206 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
60 C ELECTRO CE401~414 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 131 WIRE JUMPER JW207~210 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
61 C ELECTRO CE415 CEXF1H100V 50V RSS 10MF (5X11) TP O O 132 WIRE JUMPER JW211 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
62 C ELECTRO CE416 CEXF1C221V 16V RSS 220MF (8X11.5) TP O O 133 WIRE JUMPER JW212 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
63 C ELECTRO CE601~602 CEXF1E470V 25V RSS 47MF (5X11) TP O O 134 WIRE JUMPER JW213 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
64 C ELECTRO CE603~606 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 135 WIRE JUMPER JW214 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
65 C ELECTRO CE607~608 CEXF1E470V 25V RSS 47MF (5X11) TP O O 136 WIRE JUMPER JW216 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
66 C ELECTRO CE609~610 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 137 WIRE JUMPER JW219 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
67 C ELECTRO CE611~612 CEXF1H228V 50V RSS 0.22MF (5X11) TP O O 138 WIRE JUMPER JW220~221 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
68 C ELECTRO CE613~614 CEXF1E470V 25V RSS 47MF (5X11) TP O O 139 WIRE JUMPER JW401~404 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO O O
69 C ELECTRO CE615 CEXF1H109V 50V RSS 1MF (5X11) TP O O 140 WIRE JUMPER JW405 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
70 C ELECTRO CE616 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 141 WIRE JUMPER JW406 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
71 C ELECTRO CE617 CEXF1C101V 16V RSS 100MF (6.3X11) TP O O 142 WIRE JUMPER JW407 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
MODEL
LOCATION PART-CODE PART-DESCPART-DESC NO PART-NAMENO PART-NAME LOCATION PART-CODE
MODEL
Model : XL-211/212W
