Daewoo RL-211W - Electrical Part List(Option List)

Electrical Parts List(Option Parts List)
20
Model : XL-211/212W
1.MODEL OPTION(R705)
PCB FRONT AS
R705 JUMPER 330 680 1.2K 1.8K 2.7K 3.9K 6.8K
CASS. DECK A/S A/S A/R A/R A/S A/S A/R A/R
PSM ST-BY PSM ST-BY PSM ST-BY PSM ST-BY PSM
CD PICK UP S.SUNG S.SUNG S.SUNG S.SUNG SONY SONY SONY SONY
cf. A/S : AUTO STOP DECK
A/R : AUTO REVERSE DECK
ST-BY : STAND-BY MODE
PSM : POWER SAVE MODE
S.SUNG : SAMSUNG
2. POWER SAVE OPTION
PCB FRONT AS
LOC PART NAME
JW712 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
LD710 LED DLTL307EE- LTL-307EE(RED) PI5
Q706 TR TZRC111M-- KRC111M(AUTO)
R735 R CARBON FILM RD-AZ392J- 1/6W 3.9K
J
J
R736 R CARBON FILM RD-AZ561J- 1/6W 560
J
J
R705 R CARBON FILM
PCB MAIN AS
LOC PART NAME
CW901 CONN WAFER 9728813200 UL1617 #22 5P P=2.5X150MM
D905 DIODE DZN4148--- 1N4148 AUTO 52MM
JW905 JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO
PCB P/T AS
LOC PART NAME
CC980 C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING)
CE980 C ELECTRO CEYF1E102V 25V RSS 1000MF (13X20)
CM910 C MYLAR CMXM1H473J 50V 0.047MF
CM911 C MYLAR CMXM1H473J 50V 0.047MF
D980 DIODE D1N4001--- 1N4001
D981 DIODE D1N4001--- 1N4001
D982 DIODE D1N4001--- 1N4001
D983 DIODE D1N4001--- 1N4001
D984 DIODE D1N4001--- 1N4001
D985 DIODE D1N4001--- 1N4001
IC980 IC 1KA78L05AZ KA78L05AZ
JW903 WIRE JUMPER
JW905 WIRE JUMPER W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
JW906 WIRE JUMPER W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
PT980 TRANS POWER 5TP8028829 EI=28X12 230V 50HZ
Q981 TR TZTC3205Y- KTC3205Y (2236Y)
RY980 SW RELAY 5SC2001A01 SDT-S-105LMR
R981 R CARBON FILM RD-4Z101J- 1/4 100 OHM J
R982 R CARBON FILM RD-AZ103J- 1/6W 10K
J
J
R983 R CARBON FILM RD-AZ103J- 1/6W 10K
J
J
MODEL OPTION
10 MM JUMPER
X
X
WITH POWER SAVE
WITH POWER SAVE
X
WITHOUT POWER SAVE WITH POWER SAVE
X
X
X
X
X
O(6 MM JUMPER)
WITHOUT POWER SAVE
X
WITHOUT POWER SAVE
X
3P(S/N:972881300)
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
3. FTZ OPTION
PCB MAIN AS
LOC PART NAME
CF001 FILTER CERA 5PE107MJA- SFE 10.7MHZ RED
CF002 FILTER CERA 5PE107MJA- SFE 10.7MHZ RED
L102 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
TU001
TUNER PACK
9737613501 KST-F404VA
X
9737613201
FULL FTZ
5PE107MS3-
SIMPLE
5PE107MS3-
