Electrical Parts List(Option Parts List)
21
Model : XL-211/212W
5.TUNER BAND OPTION(R706)
PCB FRONT AS
Function
AM1 AM2 E/2B JAPAN ASIA1/12 ASIA2/24 CIS S/AM E2-2
RDS O
BAND FM/AM FM/AM FM/MW FM/AM FM/AM FM/AM FM/FM/MW FM/AM FM/MW
NO HOUR 12 12 24 12 12 24 24 12 24
STEP 100/10 200/10 ‘50/9 100/9 100/9 100/9 ‘10/50/9 100/10 ‘50/9
1 R706 JW 330 1.2K 1.8K 2.7K 3.9K 6.8K 10K 22K
1 87.5MHz 87.5MHz 87.5MHz 76MHz 87.5MHz 87.5MHz 65MHz 87.5MHz 87.5MHz
2 90 90,1 90 80 90 90 67,1 90 90
CH 3 98 98,1 98 92 98 98 69,5 98 98
4 106 106,1 106 104 106 106 72,1 106 106
5 108 108,1 108 108 108 108 74 108 108
100KHz 200KHz 50KHz 100KHz 100KHz 100KHz 10KHz 100KHz 50KHz
1 520KHz 520KHz 522KHz 522KHz 522KHz 522KHz 87.5MHz 520KHz 522KHz
2 600 600 603 603 603 603 90 600 603
CH 3 1000 1000 999 999 999 999 98 1000 999
4 1400 1400 1404 1404 1404 1404 106 1400 1404
5 1710 1710 1620 1620 1620 1620 108 1620 1620
10KHz 10KHz 9KHz 9KHz 9KHz 9KHz 50KHz 10KHz 9KHz
1 522KHz
2 "
CH 3 "
4 "
5 "
9KHz
STEP
STEP
STEP
4. RDS OPTION
PCB FRONT AS
LOC PART NAME
JW705 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO
JW706 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO
R750 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO
R751 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO
* BAND OPTION R706 : 22
K
PCB MAIN AS
LOC PART NAME
CC270 C CERA CCXB1H331K 50V B 330PF K
CC272 C CERA CCXF1H103Z 50V F 0.01MF Z
CC276 C CERA CXCH1H220J 50V CH 22PF J
CC277 C CERA CXCH1H220J 50V CH 22PF J
CE270 C ELEC CEXF1H100V 50V RSS 10MF (5X11)
CE271 C ELEC CEXF1H100V 50V RSS 10MF (5X11)
IC270 IC 1LC72723M- LC72723M
JW219 JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
L270 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
R270 R CARBON FILM RD-AZ470J- 1/6W 47 OHM J
R271 R CARBON FILM RD-AZ103J- 1/6W 10KOHM J
R272 R CARBON FILM RD-AZ103J- 1/6W 10KOHM J
XC270 X-TAL 5XA4R332M- 4.332M
