RL-211W RL-212W RL-211W RL-212W
MODEL
LOCATION PART-CODE PART-DESCPART-DESC NO PART-NAMENO PART-NAME LOCATION PART-CODE
MODEL
285 X-TAL XC270 5XA4R332M- 4.332M O O 71 R CARBON FILM R742 RD-AZ222J- 1/6 2.2K OHM J O O
1 PCB FRONT B701 9CD6586000 163X103X1.6T O O 72 R CARBON FILM R743 RD-AZ102J- 1/6 1K OHM J O O
2 C CERA CC701~702 CCXF1H223Z 50V F 0.022MF Z (TAPPING) O O 73 R CARBON FILM R744~745 RD-AZ120J- 1/6 12 OHM J O O
3 C CERA CC703 CCXF1H104Z 50V F 0.1MF Z O O 74 R CARBON FILM R746 RD-AZ222J- 1/6 2.2K OHM J O O
4 C CERA CC704~709 CCXF1H223Z 50V F 0.022MF Z (TAPPING) O O 75 R CARBON FILM R747 RD-AZ102J- 1/6 1K OHM J O O
5 C CERA CC710 CZCH1H150J 50V CH 15PF J (AXIAL) O O 76 R CARBON FILM R748~749 RD-AZ120J- 1/6 12 OHM J O O
6 C CERA CC711 CZCH1H180J 50V CH 18PF J (AXIAL) O O 77 WIRE JUMPER R750~751 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
7 C CERA CC712~713 CZCH1H330J CH 50V 33PF J AXIAL 52MM O O 78 R CARBON FILM R752~757 RD-AZ103J- 1/6 10K OHM J O O
8 C ELECTRO CE701 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 79 R CARBON FILM R760~762 RD-AZ103J- 1/6 10K OHM J O O
9 C ELECTRO CE702 CEXF1H100V 50V RSS 10MF (5X11) TP O O 80 SW TACT SW701~716 5S50101001 KPT-1105A 1C-1P O O
10 C ELECTRO CE703 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O 81 X-TAL XC701 5XA32R768- DT-38 32.768KHZ 20PPM O O
11 C ELECTRO CE704 CEYF1A102V 10V 1000MF RSS 10X16 O O 82 RESONATOR XC702 5PCSA8MTZ- CSALA8M00T55-B0 (8.00MTZ) O O
12 CONN AS CN704 9728813600 FFC 8P P=1.25X80MM K O O 1 PCB CD B501 9CD6585000 123.5X123.5X1.6T O O
13 CONN AS CN705 9728812800 UL2468 #26 3P P=2.0X130MM O O 2 C CERA CC501~502 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
14 CONN WAFER CW701 9736407900 52084-1010 10P BOTTOM O O 3 C CERA CC504~505 CCXF1H104Z 50V F 0.1MF Z O O
15 CONN WAFER CW702 9736407900 52084-1010 10P BOTTOM O O 4 C CERA CC506~507 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
16 CONN AS CW703 9CD6261300 52492-1320 BOTTOM ENTRY O O 5 C CERA CC508 CCXF1H104Z 50V F 0.1MF Z O O
17 CONN WAFER CW704 9CD6266800 52044-0845 SIDE ENTRY O O 6 C CERA CC510~512 CCXB1H222K 50V B 2200PF K (TAPPING) O O
18 CONN AS CW705 9728812800 UL2468 #26 3P P=2.0X130MM O O 7 C CERA CC513~516 CCXF1H104Z 50V F 0.1MF Z O O
19 DIODE D701~705 DZN4148--- 1N4148 AUTO 52MM O O 8 C CERA CC520 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
20 IC IC701 137560211W U-COM M37560MF-XXXGP O O 9 C CERA CC521 CCXF1H683Z 50V F 0.068MF Z O O
21 IC IC702 1M24C04--- M24C04-BN6 O O 10 C CERA CC523 CCXF1H104Z 50V F 0.1MF Z O O
22 IC IC703 1354HF7--- 354HF7 O O 11 C CERA CC524 CCXB1H391K 50V B 390PF K (TAPPING) O O
23 WIRE JUMPER JW701~704 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 12 C CERA CC525 CCXF1H104Z 50V F 0.1MF Z O O
24 WIRE JUMPER JW705~706 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 13 C CERA CC526 CCXB1H681K 50V B 680PF K (TAPPING) O O
25 WIRE JUMPER JW707 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 14 C CERA CC527 CCXB1H222K 50V B 2200PF K (TAPPING) O O
26 WIRE JUMPER JW708~709 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 15 C CERA CC528 CCXF1H104Z 50V F 0.1MF Z O O
27 WIRE JUMPER JW710 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 16 C CERA CC530 CCXB1H682K 50V B 6800PF K (TAPPING) O O
28 WIRE JUMPER JW711 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 17 C CERA CC531 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
29 WIRE JUMPER JW712~714 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 18 C CERA CC532 CCXF1H473Z 50V F 0.047MF Z (TAPPING) O O
30 WIRE JUMPER JW715 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 19 C CERA CC533 CCXF1H104Z 50V F 0.1MF Z O O
31 WIRE JUMPER JW716 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 20 C CERA CC534 CCXB1H102K 50V B 1000PF K (TAPPING) O O
32 LCD LC701 DS0295TM-- S0295T/M O O 21 C CERA CC535~536 CCXF1H104Z 50V F 0.1MF Z O O
33 LED LD701~708 DSLR342MG- SLR-342MG O O 22 C CERA CC537 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
34 LED LD710 DLTL307EE- LTL-307EE(RED)PI5 O O 23 C CERA CC538 CCXB1H222K 50V B 2200PF K (TAPPING) O O
35 TR Q701 TKRC107M-- KRC 107-M (TAPPING) O O 24 C CERA CC539 CCXB1H562K 50V B 5600PF K (TAPPING) O O
36 TR Q702 TZTA1273Y- KTA1273Y(966Y) O O 25 C CERA CC540 CXCH1H409D 50V CH 4PF D (TAPPING) O O
37 TR Q703 TKRC107M-- KRC 107-M (TAPPING) O O 26 C CERA CC541 CXCH1H270J 50V CH 27PF J (TAPPING) O O
38 TR Q704 TZTA1273Y- KTA1273Y(966Y) O O 27 C CERA CC542 CCXB1H102K 50V B 1000PF K (TAPPING) O O
39 TR Q705 TKRC107M-- KRC 107-M (TAPPING) O O 28 C CERA CC543~545 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
40 TR Q706 TKRC111M-- KRC111M (KSR1010) O O 29 C CERA CC546 CCXF1H473Z 50V F 0.047MF Z (TAPPING) O O
41 R CARBON FILM R701~702 RD-AZ103J- 1/6 10K OHM J O O 30 C ELECTRO CE502~503 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
42 R CARBON FILM R703~704 RD-AZ472J- 1/6 4.7K OHM J O O 31 C ELECTRO CE504 CEXF1E470V 25V RSS 47MF (5X11) TP O O
43 R CARBON FILM R705 RD-AZ331J- 1/6 330 OHM J O O 32 C ELECTRO CE505~507 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
44 R CARBON FILM R706 RD-AZ223J- 1/6 22K OHM J O O 33 C ELECTRO CE511 CEXF1H100V 50V RSS 10MF (5X11) TP O O
45 R CARBON FILM R707 RD-AZ331J- 1/6 330 OHM J O O 34 C ELECTRO CE513 CEXF1H100V 50V RSS 10MF (5X11) TP O O
46 R CARBON FILM R708~710 RD-AZ103J- 1/6 10K OHM J O O 35 C ELECTRO CE514~515 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
47 R CARBON FILM R711 RD-AZ101J- 1/6 100 OHM J O O 36 C ELECTRO CE516 CEXF1C221V 16V RSS 220MF (8X11.5) TP O O
48 R CARBON FILM R712 RD-AZ151J- 1/6 150 OHM J O O 37 C ELECTRO CE520 CEXF1H100V 50V RSS 10MF (5X11) TP O O
49 R CARBON FILM R713 RD-AZ181J- 1/6 180 OHM J O O 38 C ELECTRO CE521 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
50 R CARBON FILM R714 RD-AZ271J- 1/6 270 OHM J O O 39 C ELECTRO CE522~524 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
51 R CARBON FILM R715 RD-AZ331J- 1/6 330 OHM J O O 40 C ELECTRO CE525 CEXF1E330V 25V RSS 33MF (5X11) TP O O
52 R CARBON FILM R716 RD-AZ391J- 1/6 390 OHM J O O 41 C ELECTRO CE526 CEXF1C102V 16V RSS 1000MF (10X20) TP O O
53 R CARBON FILM R717 RD-AZ471J- 1/6 470 OHM J O O 42 C ELECTRO CE527~528 CEXF1H478V 50V RSS 0.47MF (5X11) TP O O
54 R CARBON FILM R719 RD-AZ152J- 1/6 1.5K OHM J O O 43 CONN AS CN500 9728813800 FFC 16P P=1.0X120MM R O O
55 R CARBON FILM R721 RD-AZ101J- 1/6 100 OHM J O O 44 CONN AS CN501 9728813900 UL1007 #30 6P P=2.0X120MM O O
56 R CARBON FILM R722 RD-AZ151J- 1/6 150 OHM J O O 45 CONN AS CN503 9728813700 FFC 13P P=1.25X120 MM R O O
57 R CARBON FILM R723 RD-AZ181J- 1/6 180 OHM J O O 46 CONN AS CN509 9728813500 6P 100MM P=2.5 BOARD-IN O O
58 R CARBON FILM R724 RD-AZ271J- 1/6 270 OHM J O O 47 CONN AS CN511 9728812900 UL1007 #26 2P P=2.5X100MM O O
59 R CARBON FILM R725 RD-AZ331J- 1/6 330 OHM J O O 48 CONN WAFER CW500 9CD6259300 52807-1610 SID ENTRY O O
60 R CARBON FILM R726 RD-AZ391J- 1/6 390 OHM J O O 49 CONN AS CW501 9728813900 UL1007 #30 6P P=2.0X120MM O O
61 R CARBON FILM R727 RD-AZ471J- 1/6 470 OHM J O O 50 CONN WAFER CW503 9CD6264500 52045-1345 TOP ENTRY O O
62 R CARBON FILM R729 RD-AZ152J- 1/6 1.5K OHM J O O 51 CONN AS CW511 9728812900 UL1007 #26 2P P=2.5X100MM O O
63 R CARBON FILM R730 RD-AZ103J- 1/6 10K OHM J O O 52 IC SSP IC501 1S1L9226-- S1L9226 O O
64 R CARBON FILM R731 RD-AZ106J- 1/6 10M OHM J O O 53 IC DSP IC502 1S5L9290-- S5L9290 O O
65 R CARBON FILM R732 RD-AZ334J- 1/6 330K OHM J O O 54 IC IC503 174HCT04AF TC74HCT04AF O O
66 R CARBON FILM R733 RD-AZ101J- 1/6 100 OHM J O O 55 IC CHIP IC504 1KA9258D-- KA9258D O O
67 R CARBON FILM R734 RD-AZ100J- 1/6 10 OHM J O O 56 WIRE JUMPER JW501 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
68 R CARBON FILM R735 RD-AZ392J- 1/6 3.9K OHM J O O 57 WIRE JUMPER JW502 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
69 R CARBON FILM R736 RD-AZ561J- 1/6 560 OHM J O O 58 WIRE JUMPER JW503 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O
70 R CARBON FILM R740~741 RD-AZ221J- 1/6 220 OHM J O O 59 WIRE JUMPER JW504 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
