Daewoo RN-331N - 3-2. Cover Multi-Flow Duct (Fresh Food Compartment)

3. DISASSEMBLY
3-2. Cover Multi-Flow Duct As (in Fresh food Compartment)
No No
1
Unlock the lamp window Unlock the 'COVER M/FLOW DUCT'
(1) Push the window right side (1) Check the marks of locking position on 'Cover'.
(2) Lever two window lock with flat driver (Number of the marks are model dependent)
(2) Push the 'cover' inside and Unlock.
Open window turning on the axis 'A'
Remove two screw cap with flat driver.
Unscrew 2 points Disconnect the Lamp & Sensor wire housing.
3
2
5
Procedure
Procedure
4
(1) Push
(2) Lever
(2) Lever
'A' axis
unscrew
unscrew
screw cap
Push
Push
the Mark of Locking Position
