(05) Engine brake data
Select sensor data LID
DV11 STEP3 engine ECU
[01] Engine start data
[02] Injector data
[03] Voltage data
[04] Fuel pressure data
[05] Engine brake data
[06] CAN communication data
[07] Fan clutch data
[08] Data logging
[09] Switch data
[10] Sensor data
Check sensor data
01. Accelerator pedal depression ······· 0.0[%]
02. Faulty accelerator pedal sensor ··········· 0
03. Engine brake #1 operation ············ [OFF]
04. Engine brake #2 operation ············ [OFF]
05. Clutch S/W ····························[INACTIVE]
06. Faulty clutch S/W ·································· 0
07. Engine brake #1 S/W ············[INACTIVE]
08. Engine brake #2 S/W ··············· [ACTIVE]
09. Engine RPM ································0 [rpm]
10. Engine oil pressure ··················845 [hPa]
Fix Un Main
▲,▼
Press
[Enter]
key
Check sensor data
11. Faulty engine oil pressure sensor ········· 0
12. Engine oil temperature ············· 27.5 [°C]
13. Faulty engine oil temperature sensor ··· 0
14. Parking brake switch ··············· [ACTIVE]
15. Foot brake S/W #1 ················[INACTIVE]
16. Foot brake S/W #2 ················[INACTIVE]
17. Foot brake S/W #3 ················[INACTIVE]
18. Faulty foot brake S/W ··························· 0
19. Vehicle speed ························· 0.0 [km/h]
20. Faulty vehicle speed sensor ················· 0
Fix Un Main
▲,▼
Press
[PgDn] key
Check sensor data
21. Fuel supply amount ··············· 0.0 [mg/st]
······································································
01. Accelerator pedal depression ······ 0.0 [%]
02. Faulty accelerator pedal sensor ··········· 0
03. Engine brake #1 operation ············ [OFF]
04. Engine brake #2 operation ············ [OFF]
05. Clutch S/W ····························[INACTIVE]
06. Faulty clutch S/W ·································· 0
07. Engine brake #1 S/W ············[INACTIVE]
08. Engine brake #2 S/W ··············· [ACTIVE]
Fix Un Main
▲,▼
Press
[PgDn]
key
To Previous Page
