Daewoo SCAN-200 - Faulty Battery Voltage

17
System Diagnostic Manual
(03) Voltage data
Select sensor data LID
DV11 STEP3 engine ECU
[01] Engine start data
[02] Injector data
[03] Voltage data
[04] Fuel pressure data
[05] Engine brake data
[06] CAN communication data
[07] Fan clutch data
[08] Data logging
[09] Switch data
[10] Sensor data
Check sensor data
01. Battery voltage ····························24.1 [V]
02. Faulty battery voltage ··························· 0
03. ECU condenser #1 voltage ·········81.0 [V]
04. Faulty condenser #1 voltage status ······ 0
05. ECU condenser #2 voltage ·········81.1 [V]
06. Faulty condenser #2 voltage status ······ 0
07. Ignition switch ··································[ON]
08. Faulty injector 1 (DV11:1) ····················· 0
09. Faulty injector 2 (DV11:4) ····················· 0
10. Faulty injector 3 (DV11:2) ····················· 0
Fix Un Main
▲,▼
Press
[Enter]
key
Check sensor data
11. Faulty injector 4 (DV11:5) ····················· 0
12. Faulty injector 5 (DV11:3) ····················· 0
13. Faulty injector 6 (DV11:6) ····················· 0
14. Self-diagnosis fault blink code1 ············ 0
15. Self-diagnosis fault blink code2 ············ 0
16. Self-diagnosis S/W ························ [OFF]
17. Self-diagnosis lamp ······················· [OFF]
18. Main relay OFF in ECU ························ 0
19. Faulty air heater lamp ··························· 0
20. Faulty self-diagnosis lamp ···················· 0
Fix Un Main
▲,▼
Press
[PgDn] key
Check sensor data
21. Faulty air heater relay ··························· 0
22. Faulty engine brake #2 output ·············· 1
23. Faulty engine brake #1 output ·············· 0
24. Faulty RPM tachometer ························ 0
25. Faulty high-pressure pump pulse ········· 0
······································································
01. Battery voltage ····························24.1 [V]
02. Faulty battery voltage ··························· 0
03. ECU condenser #1 voltage ·········81.0 [V]
04. Faulty condenser #1 voltage status ······ 0
Fix Un Main
▲,▼
Press
[PgDn]
key
