Daewoo SCAN-200 - 2. How to check engine DTCs; Navigating the Diagnostic System Menu

9
System Diagnostic Manual
Press [ENTER] key after
selecting [ECU Information]
Press
Enter
Key
Press
Enter
Key
Press
Enter Key
Press
Press
Enter Key
* It is necessary to check engine ECU
version before selection.
1. Select [ECU Information].
2. Check the ECU version (4.1:STEP3).
2. How to check engine DTCs
■
Push diagnosis device (SCAN-200) ‘PWR’ S/W on
MAIN MENU
Vehicle/engine diagnosis
1] Vehicle/engine diagnosis
2] General OBD-II
3] Snap-shot analysis
4] Tool related mode
5] Special mode
Select the above item.
SELECT CHECK ITEM
DV11 STEP3 engine ECU
1] Check DTC
2] Check sensor data
3] Erase DTC
4] Compression amount test
5] Runup test
6] Remote control
7] ECU information
3 FAULTS FOUND
B=BLINK CODE, C=CURRENT FAULT, H=HISTORICAL FAULT
DV11 STEP3 engine ECU
CB 4.2 Engine RPM sensor (Crankshaft side)
HB 7.1 diagnostic lamp
CB 3.2 Abnormal rail pressure
SELECT VEHICLE TYPE
DV11 STEP3
1] DL08 “STEP3”
2] DV11 “STEP3”
3] DL08
4] DV11
5] CNG (GE12TI & GE08TI)
6] DE12TIS
ECU INFORMATION
DV11 STEP3 engine ECU
VIN : DAEWOO BUS
DATA SET : EUJBE_A02
LAST TEST USER : Tester
S/W VERSION : 4.1
ENGINE TYPE : P41741.A2L and P41741.HEX
Prog .Date :
TEST DATE :
Frame Serial Number : Cus. str2
Vehicle Type Code : BH120F
SYSTEM SELECT
1] Engine system diagnosis
2] Vehicle system diagnosis (ABS/ASR)
3] Vehicle system diagnosis (Keyless entry)
Select the above item.
