3. Check sensor data
3-1. Select by group
■
Data group (02-1)
Check sensor data
01. Accelerator pedal depression ······ 0.0 [%]
02. Faulty accelerator pedal sensor ··········· 0
03. Low idle switch ································[ON]
04.
Accelerator pedal sensor voltage
410 [mV]
05. Barometric pressure ··············1000 [hPa]
06. Faulty barometric pressure sensor ······· 0
07. Ambient temperature ················ 40.0 [°C]
08. Faulty ambient temperature sensor ······ 1
09. Battery voltage ····························24.1 [V]
10. Faulty battery voltage ··························· 0
Fix Un Main
▲,▼
Check sensor data
11. Engine brake #1 operation ············ [OFF]
12. Engine brake #2 operation ············ [OFF]
13. ECU condenser #1 voltage ·········81.0 [V]
14. Faulty condenser #1 voltage status ······ 0
15. ECU condenser #2 voltage ·········81.1 [V]
16. Faulty condenser #2 voltage status ······ 0
17. Boost pressure ························997 [hPa]
18. Faulty boost pressure sensor ··············· 0
19. Charged air amount ············· 2357 mg/st]
20. Charged air temperature ·········· 28.5 [°C]
Fix Un Main
▲,▼
Check sensor data
21. Faulty charged air temperature sensor ··· 0
22. Faulty cam sensor ································ 0
23. Cruise SET/UP S/W ······················ [OFF]
24. Cruise SET/DOWN S/W ················ [OFF]
25. Cruise RESUME S/W ···················· [OFF]
26. Cruise OFF S/W ······························[ON]
27. Cruise speed control ················ [ACTIVE]
28. Clutch S/W ····························[INACTIVE]
29. Faulty clutch S/W ·································· 0
30. Faulty crank sensor ······························ 0
Fix Un Main
▲,▼
Select sensor data LID
DV11 STEP3 engine ECU
01] Data group [02-1]
02] Data group [02-2]
03] Data group [03]
04] Data group [14]
Press
[Enter]
key
Press
[Enter]
key
Press
[PgDn]
key
Press
Enter Key
Select check item
DV11 STEP3 engine ECU
1] Check DTC
2] Check sensor data
3] Erase DTC
4] Compression amount test
5] Runup test
6] Remote control
7] ECU information
Select sensor data type
DV11 STEP3 engine ECU
1] Select by group
2] Select by function
Press
[PgDn] key
