Electrical Parts List
NO PART-NAME LOCATION PART-CODE PART-DESC REMARK NO PART-NAME LOCATION PART-CODE PART-DESC REMARK
129 C ELECTRO CE606 CEXF1H229V 50V RSS 2.2MF (5X11) TP 193 IC IC202 1LC72131D- LC72131D
130 C ELECTRO CE608 CEXF1E470V 25V RSS 47MF (5X11) TP 194 IC REGULATOR IC205 1KA78L05AZ KA78L05AZ
131 C ELECTRO CE609 CEXF1H339V 50V RSS 3.3MF (5X11) TP 195 IC IC401 1TDA7440D- TDA7440D
132 C ELECTRO CE610 CEXF1H100V 50V RSS 10MF (5X11) TP 196 IC MOTOR DRIVE IC501 1BA5939S-- BA5939S
133 C ELECTRO CE611~612 CEXF1E470V 25V RSS 47MF (5X11) TP 197 IC CHIP RF IC502 1KB9223--- KB9223 RF+SSP+AF
134 C ELECTRO CE613~614 CEXF1H100V 50V RSS 10MF (5X11) TP 198 IC CHIP DSP IC503 1KS9286B-- KS9286B DSP+DAC
135 C ELECTRO CE615~616 CEXF1H109V 50V RSS 1MF (5X11) TP 199 IC IC601 1TA8189N-- TA8189N
136 C ELECTRO CE617~618 CEXF1E470V 25V RSS 47MF (5X11) TP 200 IC SWITCHING IC602 1BA7755A-- BA7755A (HEAD SW)
137 C ELECTRO CE619 CEXF1H229V 50V RSS 2.2MF (5X11) TP 201 IC IC801 1TDA7499-- TDA7499
138 C ELECTRO CE621~623 CEXF1E470V 25V RSS 47MF (5X11) TP 202 IC IC901 1L4959---- L4959
139 C ELECTRO CE624 CEXF1H229V 50V RSS 2.2MF (5X11) TP 203 COIL BEAD JW404 5LX159P829 1.5UH MIN
140 C ELECTRO CE626 CEXF1E470V 25V RSS 47MF (5X11) TP 204 DIODE JW411 DZN4148--- IN4148 AUTO 52MM
141 C ELECTRO CE627 CEXF1E330V 25V RSS 33MF (5X11) TP 205 R CARBON FILM JW507 RD-AZ102J- 1/6 1K OHM J
142 C ELECTRO CE801~803 CEXF1H109V 50V RSS 1MF (5X11) TP 206 COIL BEAD JW539 5LX159P829 1.5UH MIN
143 C ELECTRO CE804~805 CEXF1H100V 50V RSS 10MF (5X11) TP 207 COIL BEAD JW551 5LX159P829 1.5UH MIN
144 C ELECTRO CE806 CEXF1E470V 25V RSS 47MF (5X11) TP 208 JACK ANT J001 9736322201 PAT-646
145 C ELECTRO CE901~903 CEXF1E222V 25V RSS 2200MF (16X25) TP 209 JACK RCA J401 9CD6313700 S-436P
146 C ELECTRO CE904~907 CEXF1H229V 50V RSS 2.2MF (5X11) TP 210 JACK HEADPHONE J801 9766319501 HTJ-064-05B GOLD
147 C ELECTRO CE911~914 CEXF1H470V 50V RSS 47MF (6.3X11) TP 211 JACK SPEAKER J802 9736320500 CJ-9007-040
148 FILTER CERA CF001~002 5PE107MS3A SFELA10M7HA00-B0 212 COIL PEAKING L001 5CPZ100K02 10UH K (AXIAL 3.5MM)
149 FILTER CF201 5PPCFAZ077 PCFAZ077 213 AM RF UNIT L101 5LR0000835 KSNT 213M-1
150 C MYLAR CM201~202 CMXM2A223J 100V 0.022MF J 214 COIL PEAKING L251 5CPZ100K02 10UH K (AXIAL 3.5MM)
151 C MYLAR CM405~408 CMXM2A104J 100V 0.1MF J 215 COIL BIAS OSC L601 5L0503K643 SM-10F 5.04MH
152 C MYLAR CM409~410 CMXM2A562J 100V 5600PF J 216 TR Q001 TZTC3194Y- KTC3194Y
153 C MYLAR CM603~604 CMXM2A223J 100V 0.022MF J 217 TR Q003 TZRA107M-- KRA107M (KSR2006)
154 C MYLAR CM605~606 CMXM2A102J 100V 0.001MF J 218 TR Q501 TZTA1266Y- KTA1266Y- (AUTO)(1015Y)
155 C MYLAR CM609~610 CMXM2A153J 100V 0.015MF J 219 TR Q502 TZTA1273Y- KTA1273Y(966Y)
156 C MYLAR CM611 CMXM2A223J 100V 0.022MF J 220 TR Q503 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
157 C MYLAR CM612 CMXM2A332J 100V 3300PF J 221 FET Q601~602 TKTK117Y-- KTK117(Y)
158 C MYLAR CM613 CMXM2A153J 100V 0.015MF J 222 TR Q603~604 TZTA1266Y- KTA1266Y- (AUTO)(1015Y)
159 C MYLAR CM614 CMXM2A222J 100V 2200PF J 223 TR Q605 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
160 C MYLAR CM801~802 CMXM2A104J 100V 0.1MF J 224 TR Q607 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
161 C MYLAR CM803~804 CMXM2A473J 100V 0.047MF J 225 TR Q612 TZRC111M-- KRC111M
162 C MYLAR CM901~904 CMXM2A223J 100V 0.022MF J 226 TR Q613 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
163 C MYLAR CM916~918 CMXM2A223J 100V 0.022MF J 227 TR Q614 TZRC107M-- KRC107-M TAPPING(KSR1006)
164 C MYLAR CM921~923 CMXM2A223J 100V 0.022MF J 228 TR Q615~620 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
165 CONN PIN CN401 9736407600 53095-1310 13PIN BASE 229 TR Q621 TZTA1273Y- KTA1273Y(966Y)
166 CONN PIN CN402 9736407600 53095-1310 13PIN BASE 230 TR Q626 TZTA1273Y- KTA1273Y(966Y)
167 CONN AS CN603 9738834900 UL 2468 #26 4P+3P+2P 300MM 231 TR Q627 TZRC111M-- KRC111M
168 WAFER CW101 2503-WR-02 2P S2B-XH-A 232 TR Q801~802 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
169 WAFER CW501 9738842900 16P FFC PIT1.0 233 TR Q803 TZRA111M-- KRA111M
170 WAFER CW502 2001-WS-06 6P 2.0MM 234 TR Q804 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
171 WAFER CW503 2001-WS-12 12P 2.0MM 235 TR Q805 TZRA111M-- KRA111M
172 WAFER CW601 2503-WS-03 3P 2.5MM 236 TR Q901 TZTA1274Y- KTA1274Y-
173 WAFER CW602 2503-WS-05 5P 2.5MM 237 R FUSIBLE RF901~902 RF-2F478J- 1/2W 0.47 OHM J
174 WAFER CW603 2503-WS-09 9P 2.5MM 238 R SEMI FIXED RV601 RV1417222- 1/10 2.2K OHM B V6EK-PV1S
175 WAFER CW605 2503-WS-02 2P 2.5MM 239 WIRE JUMPER R002 W581GY6095 AWG22 1/0.65 SN 6 AUTO
176 WAFER CW705 2503-WS-13 13P 2.5MM 240 R CARBON FILM R003 RD-AZ470J- 1/6 47 OHM J
177 WAFER CW991 2503-WS-08 8P 2.5MM 241 R CARBON FILM R004 RD-AZ100J- 1/6 10 OHM J
178 DIODE ZENER DZ601~602 DZTZ6R2B-- MTZ6.2B 242 R CARBON FILM R005 RD-AZ332J- 1/6 3.3K OHM J
179 DIODE ZENER DZ901 DZTZ30B--- MTZ30B 243 R CARBON FILM R006 RD-AZ681J- 1/6 680 OHM J
180 DIODE ZENER DZ902 DZTZ6R2B-- MTZ6.2B 244 R CARBON FILM R007 RD-AZ331J- 1/6 330 OHM J
181 DIODE D201 DZN4148--- IN4148 AUTO 52MM 245 R CARBON FILM R008 RD-AZ101J- 1/6 100 OHM J
182 DIODE D401~402 DZN4148--- IN4148 AUTO 52MM 246 R CARBON FILM R101 RD-AZ472J- 1/6 4.7K OHM J
183 DIODE D472~473 DZN4148--- IN4148 AUTO 52MM 247 R CARBON FILM R103~105 RD-AZ472J- 1/6 4.7K OHM J
184 DIODE D501 DZN4148--- IN4148 AUTO 52MM 248 R CARBON FILM R106 RD-AZ332J- 1/6 3.3K OHM J
185 DIODE D601~603 DZN4148--- IN4148 AUTO 52MM 249 R CARBON FILM R107 RD-AZ223J- 1/6 22K OHM J
186 DIODE D605~608 DZN4148--- IN4148 AUTO 52MM 250 R CARBON FILM R109 RD-AZ104J- 1/6 100K OHM J
187 DIODE D610 DZN4148--- IN4148 AUTO 52MM 251 R CARBON FILM R201 RD-AZ682J- 1/6 6.8K OHM J
188 DIODE D801~802 DZN4148--- IN4148 AUTO 52MM 252 R CARBON FILM R202 RD-AZ473J- 1/6 47K OHM J
189 DIODE D901~902 DIN4001--- IN4001 253 R CARBON FILM R203 RD-AZ822J- 1/6 8.2K OHM J
190 DIODE D904~907 DRL202---- RL202 254 R CARBON FILM R204A RD-AZ123J- 1/6 12K OHM J
191 DIODE D911~912 DIN4001--- IN4001 255 R CARBON FILM R204B RD-AZ183J- 1/6 18K OHM J
192 IC IC201 1LA1833N-- LA1833N 256 R CARBON FILM R205~206 RD-AZ102J- 1/6 1K OHM J
MODEL : XM-111
To Next Page
