Daewoo XM-113 - Electrical Parts List (Model: XM-113)

Electrical Parts List
NO PART-NAME LOCATION PART-CODE PART-DESC REMARK NO PART-NAME LOCATION PART-CODE PART-DESC REMARK
385 R CARBON FILM R652 RD-AZ479J- 1/6 4.7 OHM J 12 C CERA CC722 CCZF1H104Z HIKF 50V 0.1MF Z (AXIAL)
386 R CARBON FILM R653 RD-AZ473J- 1/6 47K OHM J 13 C ELECTRO CE702 CEXF1H229V 50V RSS 2.2MF (5X11) TP
387 R CARBON FILM R654 RD-AZ271J- 1/6 270 OHM J 14 C ELECTRO CE704 CEXF1A102V 10V RSS 1000MF (8X12.5) TP
388 R CARBON FILM R655 RD-AZ102J- 1/6 1K OHM J 15 C ELECTRO CE705 CEXF1E101V 25V RSS 100MF (6.3X11) TP
389 R CARBON FILM R656 RD-AZ333J- 1/6 33K OHM J 16 C ELECTRO CE706 CEXF1H229V 50V RSS 2.2MF (5X11) TP
390 R CARBON FILM R657 RD-AZ470J- 1/6 47 OHM J 17 C ELECTRO CE708 CEXF1H100V 50V RSS 10MF (5X11) TP
391 R CARBON FILM R658 RD-AZ473J- 1/6 47K OHM J 18 C ELECTRO CE711 CEXF1H229V 50V RSS 2.2MF (5X11) TP
392 R CARBON FILM R659 RD-AZ102J- 1/6 1K OHM J 19 CONN AS CN705 9728802700 #26 13P FLAT 250MM P=2.5
393 R CARBON FILM R662 RD-AZ103J- 1/6 10K OHM J 20 PIN WAFER CW401 9736407700 52084-1310 13P BOTTOM
394 R CARBON FILM R663 RD-AZ331J- 1/6 330 OHM J 21 PIN WAFER CW402 9736407700 52084-1310 13P BOTTOM
395 R CARBON FILM R664 RD-AZ472J- 1/6 4.7K OHM J 22 DIODE D704 DZN4148--- IN4148 AUTO 52MM
396 R CARBON FILM R669 RD-AZ103J- 1/6 10K OHM J 23 DIODE D706~707 DZN4148--- IN4148 AUTO 52MM
397 R CARBON FILM R670~671 RD-AZ472J- 1/6 4.7K OHM J 24 VFD FD701 DSVA09MS18 HNA-09MS18
398 R CARBON FILM R672 RD-AZ101J- 1/6 100 OHM J 25 IC IC701 1M38199278F U-COM M38199MF-278FP
399 R CARBON FILM R673 RD-AZ105J- 1/6 1M OHM J 26 IC IC702 1M24C04--- M24C04-BN6
400 R CARBON FILM R674 RD-AZ103J- 1/6 10K OHM J 27 IC PRE AMP IC705 1HEG838--- HEG838
401 R CARBON FILM R675 RD-AZ102J- 1/6 1K OHM J 28 TR Q701 TZRC107M-- KRC107-M TAPPING(KSR1006)
402 R CARBON FILM R676 RD-AZ105J- 1/6 1M OHM J 29 R CARBON FILM R351 RD-AZ101J- 1/6 100 OHM J
403 R CARBON FILM R683 RD-AZ103J- 1/6 10K OHM J 30 R CARBON FILM R352 RD-AZ151J- 1/6 150 OHM J
404 R CARBON FILM R684 RD-AZ392J- 1/6 3.9K OHM J 31 R CARBON FILM R353 RD-AZ181J- 1/6 180 OHM J
405 R CARBON FILM R685~686 RD-AZ102J- 1/6 1K OHM J 32 R CARBON FILM R354 RD-AZ271J- 1/6 270 OHM J
406 R CARBON FILM R688 RD-AZ101J- 1/6 100 OHM J 33 R CARBON FILM R355 RD-AZ331J- 1/6 330 OHM J
407 R CARBON FILM R696 RD-AZ333J- 1/6 33K OHM J 34 R CARBON FILM R356 RD-AZ391J- 1/6 390 OHM J
408 R CARBON FILM R699 RD-AZ102J- 1/6 1K OHM J 35 R CARBON FILM R357 RD-AZ471J- 1/6 470 OHM J
409 R CARBON FILM R803~804 RD-AZ102J- 1/6 1K OHM J 36 R CARBON FILM R358 RD-AZ561J- 1/6 560 OHM J
410 R CARBON FILM R805~806 RD-AZ563J- 1/6 56K OHM J 37 R CARBON FILM R360 RD-AZ101J- 1/6 100 OHM J
411 R CARBON FILM R807~808 RD-AZ152J- 1/6 1.5K OHM J 38 R CARBON FILM R361 RD-AZ151J- 1/6 150 OHM J
412 R CARBON FILM R809~812 RD-4Z100J- 1/4 10 OHM J 39 R CARBON FILM R362 RD-AZ181J- 1/6 180 OHM J
413 R CARBON FILM R813 RD-AZ103J- 1/6 10K OHM J 40 R CARBON FILM R363 RD-AZ271J- 1/6 270 OHM J
414 R CARBON FILM R815~818 RD-4Z102J- 1/4 1K OHM J 41 R CARBON FILM R364 RD-AZ331J- 1/6 330 OHM J
415 R CARBON FILM R821 RD-AZ154J- 1/6 150K OHM J 42 R CARBON FILM R365 RD-AZ391J- 1/6 390 OHM J
416 R CARBON FILM R823 RD-AZ104J- 1/6 100K OHM J 43 R CARBON FILM R366 RD-AZ471J- 1/6 470 OHM J
417 R CARBON FILM R824 RD-AZ473J- 1/6 47K OHM J 44 R CARBON FILM R367 RD-AZ561J- 1/6 560 OHM J
418 R CARBON FILM R825 RD-AZ103J- 1/6 10K OHM J 45 R CARBON FILM R368 RD-AZ821J- 1/6 820 OHM J
419 R CARBON FILM R831~832 RD-AZ102J- 1/6 1K OHM J 46 R CARBON FILM R369 RD-AZ101J- 1/6 100 OHM J
420 R CARBON FILM R910 RD-AZ103J- 1/6 10K OHM J 47 R CARBON FILM R370 RD-AZ151J- 1/6 150 OHM J
421 R CARBON FILM R911 RD-AZ223J- 1/6 22K OHM J 48 R CARBON FILM R371 RD-AZ821J- 1/6 820 OHM J
422 R CARBON FILM R912~913 RD-AZ103J- 1/6 10K OHM J 49 R CARBON FILM R381 RD-AZ392J- 1/6 3.9K OHM J
423 R CARBON FILM R914 RD-AZ223J- 1/6 22K OHM J 50 R CARBON FILM R701~702 RD-AZ103J- 1/6 10K OHM J
424 R CARBON FILM R915 RD-AZ473J- 1/6 47K OHM J 51 R CARBON FILM R707 RD-AZ103J- 1/6 10K OHM J
425 R CARBON FILM R916 RD-AZ103J- 1/6 10K OHM J 52 R CARBON FILM R719~721 RD-AZ152J- 1/6 1.5K OHM J
426 R CARBON FILM R921 RD-AZ100J- 1/6 10 OHM J 53 R CARBON FILM R722 RD-AZ472J- 1/6 4.7K OHM J
427 R CARBON FILM R922 RD-AZ332J- 1/6 3.3K OHM J 54 R CARBON FILM R724 RD-AZ103J- 1/6 10K OHM J
428 R CARBON FILM R923 RD-AZ103J- 1/6 10K OHM J 55 R CARBON FILM R751 RD-AZ472J- 1/6 4.7K OHM J
429 R CARBON FILM R933~934 RD-AZ221J- 1/6 220 OHM J 56 R CARBON FILM R759 RD-AZ106J- 1/6 10M OHM J
430 R CARBON FILM R939~940 RD-AZ109J- 1/6 1 OHM J 57 R CARBON FILM R760 RD-AZ334J- 1/6 330K OHM J
431 TUNER PACK TU001 9737613201 KST-F401VA-3 58 R CARBON FILM R761 RD-AZ101J- 1/6 100 OHM J
432 WIRE LEAD W002 W1-BK11161 1P #26 110MM BK UL 1007 59 R CARBON FILM R762 RD-AZ100J- 1/6 10 OHM J
433 WIRE LEAD W003 W1-RE32161 1P #26 320MM RED UL 1007 60 R CARBON FILM R770 RD-AZ683J- 1/6 68K OHM J
434 WIRE LEAD W004 W1-BK60061 1P #26 60MM BK UL 1007 61 R CARBON FILM R773 RD-AZ103J- 1/6 10K OHM J
435
C DISCRIMINATOR
XC201 5P107MG86C CDA10.7MG86N-C 62 R CARBON FILM R775 RD-AZ103J- 1/6 10K OHM J
436 X-TAL XC251 5XA7R2000D 7.2M 63 R CARBON FILM R776 RD-AZ334J- 1/6 330K OHM J
437
RESONATOR CERA
XC501 5PCSA16R93 CSA16.93MXZ04 64 R CARBON FILM R777~778 RD-AZ104J- 1/6 100K OHM J
1 PANEL FRONT AS 13000 9CDM043800 AXM-111R 65 R CARBON FILM R779 RD-AZ334J- 1/6 330K OHM J
2 PCB FRONT B700 9CD6582700-01 247X139X1.6T 66 R CARBON FILM R783 RD-AZ223J- 1/6 22K OHM J
3 C CERA CC701 CCZF1E223Z HIKF 25V 0.022MF Z (AXIAL) 67 R CARBON FILM R784 RD-AZ683J- 1/6 68K OHM J
4 C CERA CC703 CCZF1H104Z HIKF 50V 0.1MF Z (AXIAL) 68 R CARBON FILM R785 RD-AZ122J- 1/6 1.2K OHM J
5 C CERA CC704~706 CCZF1E223Z HIKF 25V 0.022MF Z (AXIAL) 69 R CARBON FILM R785A RD-AZ104J- 1/6 100K OHM J
6 C CERA CC710 CCZF1H104Z HIKF 50V 0.1MF Z (AXIAL) 70 SW TACT SW702~709 5S50101001 KPT-1105A 1C-1P
7 C CERA CC711 CZCH1H150J CH 50V 15PF J (AXIAL) 71 SW TACT SW711~724 5S50101001 KPT-1105A 1C-1P
8 C CERA CC712 CZCH1H180J CH 50V 18PF J (AXIAL) 72 RESONATOR XC701 5PCSA8MTZ- CSA8MTZ, 8MHZ
9 C CERA CC713~714 CZSL1H330J SL 50V 33PF J (AXIAL) 73 X-TAL XC702 5XA32R768- DT-38 32.768KHZ 20PPM
10 C CERA CC715 CCZF1E223Z HIKF 25V 0.022MF Z (AXIAL) 1 PCB POWER AS 12000 9CDC055510 AMI-208MV
11 C CERA CC719 CCZF1E223Z HIKF 25V 0.022MF Z (AXIAL) 2 PCB POWER B991 9CD6582000 98X123
