User's Manual
6
5 Installation
Prior to installation, connect the siren to the hub and check the signal level at the installation
location. We recommend installing the siren in a place with the signal strength of at least 2 bars.
We recommend installing the siren with expansion screws.
Figure 5-1 Installation
Table 5-1 Installation items
No. Item name No. Item name
1 Wireless siren 4 Expansion bolt
2 ST3 × 18 mm self-tapping screw 5 Wall
3 Attachment panel
Step 1 Drill 2 holes in wall according to the hole positions of the attachment panel.
Step 2 Put the expansion bolts into the holes.
Step 3 Align the screw holes on the plate with the expansion bolts.
Step 4 Fix the attachment panel with ST3 × 18 mm self-tapping screws.
Step 5 Align the arrow engraved on the rear shell of the siren with the arrow engraved on the
attachment panel, and then x the siren into the attachment panel in the clockwise
direction.
1
2
3
4
5
