Dahua Technology IPC-HFW1320S-W User Manual

4
Indicator light status
Device status
Red light normally on
Booting
Green light slow flashing
Booting completed, await wifi config,
enter smart config status;
Green light quick flashing
Wifi smart config in progress, including
WPS (Wi-Fi Protected Setup),
management frame and etc.
Green light normally on
Wifi connection succeeded, operate
normally.
Red and green lights flash alternately
Device upgrade
Red light slow flashing
Network connection failure or
disconnection after network connection
success.
Red light quick flashing
Device malfunction, fail to boot up; alarm
or SD card malfunction
Sheet 2-3

Dahua Technology IPC-HFW1320S-W Specifications

General

Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal, Plastic
International Protection (IP) code	IP67
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	12
Power over Ethernet (PoE)	No
Power consumption (typical)	4.4 W
Type	IP security camera
Certification	CE (EN 60950:2000), UL:UL60950-1, FCC 15 B
Day/night mode	Yes
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Maximum operating distance	50 m
Mobile operating systems supported	Android, iOS
ROM capacity	16 MB
Internal memory	256 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Number of users	20 user(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Streaming method	Multicast, Unicast
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;ICMP;IGMP
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Total megapixels	3 MP
Gain control type	Auto/Manual
Maximum resolution	2304 x 1296 pixels
Supported video modes	720p, 1080p
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296
Digital zoom	16 x
Fixed focal length	2.8 mm
Maximum aperture number	2
Pan range	0 - 360 °
White balance	Auto, Lamp, Manual, Natural, Outdoor
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Minimum illumination	0 lx
LED type	IR
Night vision distance	30 m
Number of illumination LEDs	24
Sensor type	CMOS
Optical sensor size	1/3 \
Number of cameras	1
Interface	RJ-45/WLAN

Weight and Dimensions

Length	164.7 mm
Weight	430 g
Diameter	70 mm
Package weight	520 g
