User’s Manual
20
Connect cables
Put the cover back and fasten the screws.
Put back cover
Installing Device into Rack
Only DH-XVR7416L-4KL-X/DH-XVR5432L-X/DH-XVR7816S-4KL-X/DH-XVR5832S-X models support
this installation.
To install the DVR into rack, do the following:
Check whether the in-house temperature is lower than 35 °C (95 °F) and make sure the 15 cm
(6 inches) spacing around the Device for ventilation.
Use six screws to fix the DVR on each side.
Install from the bottom up.
If you want to install more accessories to the rack, take preventive measures to avoid power
socket overload.
(Optional) Install more accessories to the rack if needed.
