Dahua DH-IPC-HDW8341X-3D Series User Manual

DH Network Camera
Product Construction Instruction Manual (Passenger Flow Solution)
9
Arming requirements:
 Top mounted, with the lens forming a 90° angle with the horizontal plane.
 Sufficient lighting in the region covered by the detection image.
 No blocking of sight in the region covered by the detection image (along the passenger flow
direction).
 The detected person must be fully exposed (such as the shoulder width).
 See Figure 3.
Illustration of arming
Arming quantity:
 Installation of a single device
Figure 4 Installation of a single device
 Installation of multiple coordinated devices
Figure 5 Installation of multiple devices
Enters: 23
Exits:18
